OPERATION
Manual Tuning
1. Press the TUNE switch @ until the MANUAL indicator appears in the dot matrix
display @.
2. To select the tuning band, press the BAND button @&. The Band indicator shows your
selection.
3. To tune to higher frequencies, press the UP switch 89.
To tune to lower frequencies, press the DN switch @9.
Auto SEEK Tuning
1. Press the TUNE switch @ until the SEEK indicator @ appears in the display.
2. Select the tuning band with the BAND button 2.
3. Press the UP (pp) 4 or DN (4) @ switch. The unit automatically tunes to the next
higher or lower frequency and locks on that station.
Preset Memory Programming
Follow the instructions below to program stations into preset memory:
1. Select the tuning band (FM1, FM2, MW or LW) with the BAND button @.
2. Tune in your desired station using Manual or Auto SEEK tuning.
3. Press the Preset button number 1 @ for more than 2 seconds. The digital display @
will begin to blink. Press that preset button again while the display is blinking (within 5
seconds).
4. The frequency you selected will be placed into Preset Memory number 1 and will
appear in the display.
NOTE:
lf a preset memory has already been set in the same address, it will be cleared and
the new station will be memorized.
5. Follow steps 2 — 3 for the remaining presets (2 — 6). Use this procedure for FM1,
FM2, MW and LW.
Auto MEmory Preset
1. Press the TUNE switch @ to light up the A. ME indicator @.
2. Select the desired tuning band (FM1, FM2, MW or LW) with the BAND button 4.
3. Press the UP @ or DN @ switch. The tuner will automatically seek the 6 strongest
stations in each band and memorize them in order of the signal strength. These
stations are automatically placed in the preset memory with the strongest station in
Preset No. 1 and the 6th strongest station in Preset No. 6. When seeking stations, the
tuner first seeks in the local tuning mode. If less than 6 stations are memorized, the
tuner seeks again in the distance (DX) mode.
4. After finishing the Auto Memory Preset, the tuner goes to the station placed in Preset
Memory No. 1. If no stations are memorized, it returns to the original station you were
listening to before the Auto Memory Preset procedure began. When auto memory
presetting is completed, the A. ME indicator @ will disappear and the SEEK indicator
@ will appear.
NOTE:
The Auto Memory Preset feature also works in the D.A.P. mode.
244.2
7619R 7619R
OPERATION
Preset Tuning
After the preset stations have been memorized, you can tune in your desired station
(within the band displayed) with one touch of 4 button.
1. Select the tuning band (FM1, FM2, MW or LW) with the BAND button @
2. Press any one of the Preset buttons (@ — 2) and the number of that Preset will
illuminate in the dot matrix display @.
3. The frequency of the station placed in the selected preset location will appear in the
display.
D.A.P. (Direct Access Preset)
This feature allows the storage of FM, MW and LW presets on the same band. Press
the D.A.P. button @ to light up the D.A.P. indicator @. To program stations into the D.A.P.
band, follow steps 1 — 3 as described in the Preset Memory Programming section on
page 12.
Accessing the D.A.P. Presets
1. Press the D.A.P. button @. The D.A-P. indicator @ will illuminate in the display.
2. Press one of the preset buttons (@ — @).
3. The frequency of the station placed in the selected D.A.P. location will appear in the
display.
Switching the FM Volume
Use this function if the difference in volume is great when switching between a tape
and the FM radio.
1. Press the TUNE switch @ for 3 seconds.
2. Press the Preset No. 1 button @& to switch the display between “FM-LV Hi” and
“FM-LV Lo”.
The FM volume can be set to one of two positions, high or low. Set the position
according to the broadcast station.
FM-LV Hi FM-LV Lo
OPERATION
@ TAPE PLAYER OPERATION
Turn the unit on and press the TAPE ( P/IE) button to access the tape mode.
Dolby* B/C Noise Reduction
Before playing a cassette tape, check to see if it is encoded with Dolby B or C noise
reduction.
Press
the
Dolby
NR
B
or
C
button
(@
or
@)
when
playing
a
Dolby
NR
encoded
tape. The Dolby NR B or C indicator ® on the button will illuminate.
Cassette Loading
1. Insert a prerecorded cassette tape into the Cassette Loading Slot © with the open
side facing to your right.
2. If the cassette tape is not completely loaded into-the deck, lightly press the cassette
into the slot.
Eject
Press the Eje t button @ to eject the cassette from the tape mechanism.
Pause
To temporarily stop playback, press the TAPE ( B/I§ ) button @. To resume playback,
press the same button again.
Playback
1. Insert a prerecorded cassette tape with the open side facing right. The playback
begins immediately.
2. If a cassette tape is already loaded in the unit, press the TAPE ( »/EE ) button @ to
start playback.
3. To stop tape play, press the Eject button © or turn the power off with the POWER
On/Off switch @.
NOTE:
Push the TUNE switch @ with the tape or CD played in the A.P.I. or T. INFO mode, and
the unit will be set to the TUNER mode and the tuning is possible.
True Fast Forward and Rewind
1. Press the FF switch @ to advance the tape quickly. Press the REW switch ® to
rapidly run the tape backward. The deck will perform these functions correctly
regardless of the tape play direction.
2. To disengage the FF or REW function, press the TAPE ( »/I) button @.
-12—
