Alpine CDA-9855R User Manual

CDA-9855R
CD-DA PLAY MP3 PLAY
1 0.00V 0.00V
2 0.00V 0.00V PULSE : 3.17V (when disc scratch is detected)
3 3.17V 3.17V
4 0.00V 0.00V
5 0.00V 0.00V
PULSE : 3.17V (when disc scratch is detected)
6 0.00V 0.00V
7 3.17V 3.17V
8 3.17V 3.17V
CD-DA PLAY MP3 PLAY
1 1.65V 1.65V
2 1.60V 1.60V
3 1.59V 1.59V
4 0.00V 0.00V
5 1.56V 1.56V
6 1.56V 1.56V
7 1.56V 1.56V
8 3.17V 3.17V
CD-DA PLAY MP3 PLAY CD-DA PLAY MP3 PLAY
1 0.10V 0.10V 1 0.10V 0.10V
2 3.30V 3.30V 2 3.30V 3.30V
3 2.56V 2.56V 3 2.56V 2.56V
4 0.00V 0.00V 4 0.00V 0.00V
5 3.30V 3.30V 5 3.30V 3.30V
IC801 IC802
IC303
IC304
