CDA-9855R
Extension Cable
*Always connect the Extension Cable when making checks of voltage and repair.
DVD Deck Mechanism
DP23S8DA
MAIN P.W.Board
C
B
1
0
1
CB501
CB104
(1)
CH4001
FRONT P.W.Board
(2)
(1) 01E29616S01
(2) 01V37775S01
