Alpine CDA-9855R - Packing Assembly Parts List; Packing Method View

102
105
106
BO
TTOM
Side
101
104
103
X4
103
-2
103
-1
103
-3
103
-4
104
X1
X1
X1
X1
103
-5
X1
106
X1
CDA-9855R
Packing Assembly Parts List
Part No. Part No.
101 15D00529K02 CASE,INNER 103-4 03A60836Y01 SCR,CUS 5X7 ZN A
102 15D01798K03 CARRYING,CASE
103-5
60T55630W01 BAT,MGN R03(NB)UM-4
103-1 03S60820Y16 SCR,MCH 5X8 ZN A 104 09-02252Z01 ASSY,ANIC-0007-01A
103-2 03S60824Y01 SCR,WEV 1.7X4 ZN A 105 68-02278Z08 O/M AOEU AODL
103-3 36A02449K01 CAP,RUBBER(A) 106 97-02291Z01 ASSY,SBPF00001A
Packing Method View
Description
No. No.
Symbol SymbolDescription
