CDA-9855R
No. Symbol I/O Terminal Description
32 /BUCK O CLOCK output terminal for SERVO_LSI (TC94A14FA) interface.
33 /CCE O Chip enable output terminal for SERVO_LSI (TC94A14FA) interface.
34 /CD_RESET O SERVO_LSI (TC94A14FA) RESET output terminal.
35 ZMUTEIN I 0 detection flag input terminal for SERVO_LSI (TC94A14FA) interface.
36 NC(PULL-DOWN) - Pull-down connect terminal.
37 MUTE_0 O 0 MUTE signal output terminal for SERVO_LSI (TC94A14FA) interface.
38 NC(PULL-DOWN) - Pull-down connect terminal.
39 GVSW O RF-AMP (TC2157FN) AGC, TE, FE GAIN switching signal output terminal.
40 /DR_MUTE O MOTOR Driver (BA5985FM) MUTE output terminal.
41 MOTOR1 O Load-MOTOR control signal output terminal. (REV)
42 MOTOR2 O Load-MOTOR control signal output terminal. (FOR)
43 /LMT_SW I LIMIT detection SW signal input terminal.
44
I
48
49 CDVCONT O System SERVO 3.3V power supply control output terminal.
50 /BOOT O BOOT output terminal for Flash u-COM rewriting.
51 NC - No connect terminal.
52 /DEC_RESET O Decoder (TC94A20F) RESET output terminal.
53 DEC_STANDBY O Decoder (TC94A20F) STANDBY output terminal.
54
55
56 NC(PULL-DOWN) - Pull-down connect terminal.
57 SDA I/O
DATA input/output, EEP-ROM DATA input/output combination terminal for Decoder
(TC94A20F) interface.
58 SDL O
CLOCK output, EEP-ROM CLOCK output combination terminal for Decoder
(TC94A20F) interface.
59 /STBY(PULL-UP) - Pull-up connect terminal.
60 /SWA I Disc insertion detection SW signal input terminal.
61 /SWB I 8cm Disc Eject/reload detection SW signal input terminal.
62 /SWC I 12cm Disc Eject/reload detection SW signal input terminal.
63 /SWD I Disc chucking completion detection SW signal input terminal.
64 VREFH - BATT+3.3V power supply connect terminal.
NC(PULL-DOWN)
NC - No connect terminal.
- Pull-down connect terminal.
To Next Page
