Alpine CDA-9884R User Manual

42-EN
Connections
*
(Black) ADAPTIVE STEERING REMOTE G . GND
(Pink/Black) AUDIO INTERRUPT IN
(Green)
(Green/Black)
(White)
(White/Black)
To iPod
To Vehicle Display Interface
JASO Antenna Plug
To vehicle phone
Ignition Key
Speakers
Rear Left
Front Left
CD Changer
(Sold Separately)
Speakers
Amplifier
Amplifier
Rear Left
Front Left
To adaptive steering remote
control interface box
(Brown/Yellow) ADAPTIVE STEERING REMOTE CONTROL IN1
(Brown/Orange) ADAPTIVE STEERING REMOTE CONTROL IN2
To adaptive steering remote
control interface box
To adaptive steering remote
control interface box
ISO Antenna Plug
To amplifier or equalizer
To the instrument cluster
illumination lead
To power antenna
Battery
Front Right
Rear Right
Rear Right
Front Right
Subwoofers
(Blue/White) REMOTE TURN-ON
(Red) IGNITION
(Black) GND
(Blue) POWER ANT
BATTERY
(Yellow)
(Grey/Black)
(Grey)
(Violet/Black)
(Violet )
Antenna
Amplifier
(Black)
(Blue)
DIMMER
(Orange)
* The label is attached on the bottom of the unit.

Alpine CDA-9884R Specifications

General

Brand	Alpine
Model	CDA-9884R
Category	Car Receiver
Language	English
