Adjusting Bass Level/Treble Level/
Balance (Between Left and Right)/Fader
(Between Front and Rear)
1
Press Rotary encoder (AUDIO) repeatedly to
choose the desired mode.
Each press changes the mode as follows:
BASS TREBLE BALANCE FADER Return to normal
mode
Bass: -12 ~ +12dB
Treble: -12 ~ +12dB
Balance : L15 ~ R15
Fader : R15 ~ F15
Ř If no operation is performed for 5 seconds after selecting the BASS,
TREBLE, BALANCE or FADER mode, the unit automatically returns
to normal mode.
2
Turn the Rotary encoder until the desired sound is
obtained in each mode.
Equalizer Presets (Factory’s EQ)
6 typical equalizer settings are preset at the factory for a variety of
musical source material.
Press SOUND repeatedly until the desired Factory’s EQ
type is displayed.
With each press of the button, the equalizer mode will display
the selected equalizer characteristic.
FLAT(OFF) ROCK POP JAZZ VOCAL CLUB
FLAT(OFF)
Sound Setting
SOUND
Rotary encoder (AUDIO)
9
To Next Page
