Alpine CDE-111R User Manual

33-EN
 Full Speed Connector
Control iPhone/iPod signals.
Connect this to an iPhone/iPod by using FULL SPEED Connection
Cable (KCE-433iV) (sold separately for CDE-111R/CDE-111RM/
CDE-113BT) or to an external device (such as a portable player) by
using conversion cable (KCE-237B) for building up the AUX IN (sold
separately).
Note
• Refer to “Setting the AUX+ SETUP Mode” on page 19.
AUX+ ON :
When the external device is connected.
AUX+ OFF :
When an iPhone/iPod is connected.
You can also connect this to an optional BLUETOOTH INTERFACE
(KCE-400BT) (CDE-111R/CDE-111RM/CDE-112Ri only). To use a
hands-free mobile phone, an optional BLUETOOTH INTERFACE
(KCE-400BT) connection is required. For details on connection, refer
to the Owner’s Manual of the BLUETOOTH INTERFACE (KCE-400BT).
 Antenna Receptacle
 Audio Interrupt In Lead (Pink/Black)
Connect this lead to the Audio Interface output of a cellular phone
which provides ground shorting when a call is received.
 Remote Turn-On Lead (Blue/White)
Connect this lead to the remote turn-on lead of your amplifier or
signal processor.
 Switched Power Lead (Ignition) (Red)
Connect this lead to an open terminal on the vehicle’s fuse box or
another unused power source which provides (+) 12V only when the
ignition is turned on or in the accessory position.
 Ground Lead (Black)
Connect this lead to a good chassis ground on the vehicle. Make sure
the connection is made to bare metal and is securely fastened using
the sheet metal screw provided.
 Power Antenna Lead (Blue)
Connect this lead to the +B terminal of your power antenna, if
applicable.
Note
• This lead should be used only for controlling the vehicle’s power
antenna. Do not use this lead to turn on an amplifier or a signal
processor, etc.
 Dimmer Lead (Orange) (CDE-112Ri/CDE-113BT/ CDE-114BTi
only)
This lead may be connected to the vehicle’s instrument cluster
illumination lead. This will enable the vehicle’s dimmer control to dim
the backlighting of the unit.
 Battery Lead (Yellow)
Connect this lead to the positive (+) post of the vehicle’s battery.
 ISO Power Supply Connector
 ISO Connector (Speaker Output)
 Left Rear (+) Speaker Output Lead (Green)
 Left Rear (−) Speaker Output Lead (Green/Black)
 Left Front (+) Speaker Output Lead (White)
 Left Front (−) Speaker Output Lead (White/Black)
 Right Front (−) Speaker Output Lead (Grey/Black)
 Right Front (+) Speaker Output Lead (Grey)
 Right Rear (−) Speaker Output Lead (Violet/Black)
 Right Rear (+) Speaker Output Lead (Violet)
 Steering Remote Control Interface Connector
To steering remote control interface box.
You can operate this unit from the vehicle’s control unit when an
Alpine Steering Remote Control Interface Box (optional) is
connected. For details, contact your Alpine dealer.
 MIC Input Connector (CDE-113BT/CDE-114BTi only)
To M icrophone.
 Fuse Holder (10A)
 Front Output RCA Connectors (CDE-112Ri/CDE-113BT/
CDE-114BTi only)
RED is right and WHITE is left.
 Rear/Subwoofer Output RCA Connectors (CDE-112Ri/
CDE-113BT/CDE-114BTi only)
Front/Subwoofer Output RCA Connectors (CDE-111R/CDE-111RM
only)
RED is right and WHITE is left.
 Power Supply Connector
 RCA Extension Cable (sold separately)
 FULL SPEED Connection Cable (KCE-433iV) (sold separately
for CDE-111R/CDE-111RM/CDE-113BT)
 KCE-400BT Connection Cable (Included with KCE-400BT)
 ISO/JASO Antenna Adaptor (sold separately)
An ISO/JASO antenna adapter may be required, depending on the
vehicle.
 Front AUX Input Terminal (CDE-112Ri/CDE-113BT/
CDE-114BTi only)
This terminal allows for input of audio from an external device (such
as a portable player), using a commercially-available converter cable.
 USB Terminal
Connect this to a USB Memory (sold separately).
To prevent external noise from entering the audio system.
• Locate the unit and route the leads at least 10 cm away from the
car harness.
• Keep the battery power leads as far away from other leads as
possible.
• Connect the ground lead securely to a bare metal spot (remove
any paint, dirt or grease if necessary) of the car chassis.
• If you add an optional noise suppressor, connect it as far away
from the unit as possible. Your Alpine dealer carries various
noise suppressors, contact them for further information.
• Your Alpine dealer knows best about noise prevention
measures so consult your dealer for further information.
