24-EN
For details on the control from a BLUETOOTH compatible device, refer
to the Owner’s Manual of the BLUETOOTH compatible device.
Pairing a BLUETOOTH compatible device with
SSP (Secure Simple Pairing)
1 Using your BLUETOOTH compatible device, select the
“Alpine CD Receiver” (CDE-174BT/CDE-173BT only)/
“Alpine Digital Media Receiver” (UTE-72BT only) for
pairing.
2 Turn the Rotary encoder to change the head unit display
from “PAIR NO” to “PAIR YES”, and then press ENTER.
If “PAIR NO” is selected, the connection will be cancelled.
3 If the pairing was successful, “CONNECTED” is displayed
for a few seconds. The head unit then returns to its
previous state.
Pairing a BLUETOOTH compatible device without
SSP (Secure Simple Pairing)
1 Using your BLUETOOTH compatible device, select the
“Alpine CD Receiver” (CDE-174BT/CDE-173BT only)/
“Alpine Digital Media Receiver” (UTE-72BT only) for
pairing.
2 Input the PIN code (“0000”) in a BLUETOOTH compatible
device.
Note
• The PIN code is fixed as “0000”.
3 If the pairing was successful, “CONNECTED” is displayed
for a few seconds. The head unit then returns to its
previous state.
Notes
• If the connection is unsuccessful, “FAILED” is displayed.
• After a successful pairing, the two devices should re-pair automatically
whenever the vehicle’s ignition is turned ON. However, the re-pairing
may fail. If the auto re-pairing fails, try to pair manually.
• Set “VISIBLE M” to VISI M ON to enable this unit to be recognised by a
BLUETOOTH compatible device, refer to “Setting the Visible Mode” on
page 25.
BLUETOOTH SETUP
The following steps 1 to 5 are common to the various BLUETOOTH
functions. For details, refer to each individual function.
Note
• Set “BT IN” to ON, and then perform BLUETOOTH SETUP operation.
Refer to “Setting the BLUETOOTH Connection (BT IN)” on page 24.
1 Press and hold AUDIOSETUP for at least 2 seconds to
activate the SETUP mode.
2 Turn the Rotary encoder to select “BLUETOOTH”, and then
press ENTER.
The BLUETOOTH setup mode is activated.
3 Turn the Rotary encoder to select the desired items, and
then press ENTER.
BLUETOOTH:
BT IN
*1
 PAIRED DE V
*2
 VISIBLE M
*2
 CALL SOUND
*2

CALLER ID
*2
 PB UPDATE
*1/*2
 PB ORDER
*2
 AUTO ANS
*2
 SPEAKER SL
*2
 FW VERSION
*2
 FW UPDATE
*1
*1 The items are not displayed during a phone call.
*2 The items are not displayed if “BT IN” is set to OFF. Refer to
“Setting the BLUETOOTH Connection (BT IN)” on page 24.
4 Turn the Rotary encoder to change the settings.
5 Press and hold AUDIOSETUP for at least 2 seconds.
The SETUP mode is cancelled.
Notes
•Press r to return to the previous mode.
• Pressing and holding r for at least 2 seconds will return to normal
mode.
• If no operation is performed for 60 seconds, the unit will return to
normal mode automatically.
With BLUETOOTH technology, you can place a hands-free call by a
BLUETOOTH-equipped mobile phone.
Audio information of a BLUETOOTH compatible mobile phone, a
portable audio player, etc., is controllable/playable wirelessly from this
unit.
 Setting item: BT IN
Setting contents:
OFF / ON (Initial setting)
OFF:
Hands-Free Phone function and BLUETOOTH Audio are not used.
ON:
Select when you want to pair your BLUETOOTH compatible phone
with this unit or/and use BLUETOOTH Audio function.
Note
• When “BT IN” is set to OFF, the indicators related to Hands-free phone
(c battery quantity and i signal strength) will not be displayed.
Select one of 5 connected BLUETOOTH compatible devices that you
previously registered.
 Setting item: PAIRED DEV
1 Turn the Rotary encoder to select a BLUETOOTH
compatible device you want to use (you want to change
connection), and then press ENTER.
2 Turn the Rotary encoder to select “CONNECT”, and then
press ENTER to connect the selected device.
The connected device is marked with “l”. Select “DISCONNECT”
to disconnect this device. Select “CLEAR” when you want to clear
the device from the device list.
How to connect to a BLUETOOTH
compatible device (Pairing)
Setting the BLUETOOTH Connection
(BT IN)
Setting the BLUETOOTH Device
