39-EN
iPod/iPhone Connection (optional)
1
Open the cover of the USB Connection Terminal.
2
Connect the Interface cable for iPod directly to the USB
Connection Terminal, or via the USB cable.
* The illustration is for CDE-173BT.
Connect the USB cable to the Rear USB connector of the unit.
Remove the iPod/iPhone from Interface cable for iPod.
Notes
• This unit can charge the iPod/iPhone of the current source, and it may
stop charging when another source is switched.
• After changing the unit to a source other than the iPod, remove the
iPod/iPhone. If the iPod/iPhone is removed in the iPod mode, data may
cause damage.
• If sound is not output or the iPod/iPhone is not recognised even when
the iPod/iPhone is connected, remove the iPod/iPhone once, then
connect it again, or reset the iPod.
• Do not leave the iPod/iPhone in a vehicle for a long time. Heat and
humidity may damage the iPod/iPhone and you may not be able to play
it again.
USB Memory Connection (optional)
Connect USB Memory
1
Open the cover of the USB Port.
2
Connection the USB Memory directly to the USB Port, or
via the USB cable.
* The illustration is for CDE-173BT.
Remove USB Memory
1
Carefully, pull out the USB Memory Device from the USB
cable or the USB Port.
2
Close the cover of the USB Port.
Notes
• Change to a source other than the USB AUDIO mode, and then remove
the USB Memory Device. If USB Memory is removed in the USB
AUDIO mode, data may be damaged.
• When removing USB Memory, pull it out straight.
• If sound is not output or USB Memory is not recognised even when
connected, remove the USB Memory Device once, and then connect it
again.
• Route the USB cable away from other cables, etc.
• After removing the USB Memory, close the cover of the USB Port to
prevent dust or foreign objects from entering and causing a
malfunction.
When connect to Front USB Connection
Terminal (CDE-173BT/UTE-72BT only)
When connect to Rear USB Connector
(CDE-174BT only)
Remove the iPod/iPhone
To Next Page
