23 24
Use a trim tool to remove the factory speaker cover.
25
Tear Down: Speaker Panel
Under the grill you will nd the factory 3” speaker. Use a 10mm socket to remove the
bolts holding it in place. A precision at head screw driver will be required to release
the plug from the speaker.
26
Preperation: Front Door
Now take the provided template and place it on the rear of the door card. Using the
push clips holes to carefully line up the template. Take care during this step as it is
critical for proper installation.
Turn over the Front door cards. Remove the bottom plastic push clips from the card.
Place them aside for use later.
27
28
