Operation stopped
3 OCSET In OCSET (Add an external resistor to set
max output current.)
10.8
4 Vcc PI IC power supply pin 11.1
5 Output Out 3.79
6 Output Out
Output (Switch Pin.Connect external
inductor/diode here.Minimize trace area
at this pin to reduce EMI)
3.79
7 Vss Gnd GND pin 0
8 Vss Gnd GND pin 0
LCD Controller MST501V (U300)
Pin No. Name Type Function Description Voltage(V)
1 BB[5] I/O Port B Blue Channel Bit[7:2] 0.06
2 GND Gnd Ground 0
3 BYPAS
S
For External Bypass Capacitor 3.36
4 BB[6] I/O Port B Blue Channel Bit[7:2] 0.06
5 BB[7] I/O Port B Blue Channel Bit[7:2] 0.06
6 GPO4 Out TCON GPO[9:0] 0.74
7 GPO5 Out TCON GPO[9:0] 0.06
8 GB[2] I/O Port B Green Channel Bit[7:2] 0.06
9 GB[3] I/O Port B Green Channel Bit[7:2] 0.06
10 GND Gnd Digital Output Ground 0.06
11 VDDP PI Digital Output Power 3.42
12 GB[4] I/O Port B Green Channel Bit[7:2] 0.06
13 GB[5] I/O Port B Green Channel Bit[7:2] 0.06
14 GB[6] I/O Port B Green Channel Bit[7:2] 0.06
15 GB[7] I/O Port B Green Channel Bit[7:2] 0.06
16 GPO6 Out TCON GPO[9:0] 0.07
17 GPO7 Out TCON GPO[9:0] 3.42
18 RB[2] I/O Port B Red Channel Bit[7:2] 0.06
19 RB[3] I/O Port B Red Channel Bit[7:2] 0.06
20 VDDC PI Digital Core Power (2.5V) 2.56
21 GND Gnd Ground 0.06
22 GND Gnd Digital Output Ground 0.06
23 VDDP PI Digital Output Power 3.51
24 RB[4] I/O Port B Red Channel Bit[7:2] 0.06
25 RB[5] I/O Port B Red Channel Bit[7:2] 0.06
26 RB[6] I/O Port B Red Channel Bit[7:2] 0.06
27 RB[7] I/O Port B Red Channel Bit[7:2] 0.06
28 DDC_D
AT
I/O DDC Data for Analog Interface 2.80
29 DDC_C
LK
In DDC Clock for Analog Interface 2.68
