30 DDCRO
M_CLK
In DDC ROM Clock 2.73
31 DDCRO
M_DAT
I/O DDC ROM Data 2.73
32 HWRES
ET
In Hardware reset;active high 0.09
33 XIN In Xin 1.77
34 XOUT Out Xout 1.78
35 AVDD_
MPLL
PI MPLL Power 3.51
36 GND Gnd Ground 0.06
37 HSYNC
0
In Analog HSYNC Input 2.63
38 VSYNC
0
In Analog VSYNC Input 2.39
39 GND Gnd Ground 0
40~41 NC 0
42 GND Gnd Ground 0
43~43 NC 0
45 AVDD_
ADC
PI ADC Power 3.43
46~49 NC 0
50 REXT External resistor 390 Ohm to
AVDD_ADC
3.13
51 AVDD_
PLL
PI PLL Power 3.44
52 GND Gnd Ground 0
53
BINM
In Reference Ground for Analog Blue
Input
0
54 BINP In Analog Blue Input 0
55
GINM
In Reference Ground for Analog Green
Input
0
56
GIN0P
In Analog Green Input 0
57
SOGIN0
In Sync-On-Green Input 0.07
58
RIN0M
In Reference Ground fro Analog Red Input 0
59
RIN0P
In Analog Red Input 0
60 GND Gnd 0
61 AVDD_
ADC
PI ADC Power 3.43
62 REFP Internal ADC Top De-coupling Pin 0.06
63
REFM
Internal ADC Bottom De-coupling Pin 0.06
64 GND Gnd Ground 0
65 CS In 3 Wire Serial Bus Chip Select ;active 0.07
