Alpine PKG-2000P - TV Tuner and Disc Status; TV Tuner Control

high
66 SDA I/O 3 Wire Serial Bus Data; 4.07
67 SCL In 3Wire Serial Bus Clock 4.08
68 INT Out CPU interrupt 2.47
69
PWM0
Out PWM0 3.25
70
PWM1
Out PWM1 0.08
71
VCLK
In Video Decoder Clock 1.57
72 VD0 In Video Decoder Data[7:0] 1.21
73 VD1 In Video Decoder Data[7:0] 1.18
74 VD2 In Video Decoder Data[7:0] 1.18
75 VD3 In Video Decoder Data[7:0] 1.16
76 VD4 In Video Decoder Data[7:0] 1.76
77 VD5 In Video Decoder Data[7:0] 1.11
78 VD6 In Video Decoder Data[7:0] 1.12
79 VD7 In Video Decoder Data[7:0] 1.11
80 VDDP PI Digital Output Power 3.42
81 GND Gnd Digital Output Ground 0
82 GND Gnd Ground 0
83
VDDC
PI Digital Core Power (2.5V) 2.56
84 OSP Out TCON”Odd” Channel Start Pulse 0.06
85 ESP Out TCON”Even” Channel Start Pulse 0.06
86 BA[2] Out Port A Blue Channel Bit[7:2] 0.67
87 BA[3] Out Port A Blue Channel Bit[7:2] 0.67
88 BA[4] Out Port A Blue Channel Bit[7:2] 0.69
89 BA[5] Out Port A Blue Channel Bit[7:2] 0.71
90 BA[6] Out Port A Blue Channel Bit[7:2] 0.66
91 BA[7] Out Port A Blue Channel Bit[7:2] 0.72
92 VDDP PI Digital Output Power 3.42
93 GND Gnd Digital Output Ground 0
94 GND Gnd Ground 0
95
VDDC
PI Digital Core Power (2.5V) 2.56
96 OINV Out TCON”Odd” Channel Inversion 3.42
97 EINV Out TCON”Even” Channel Inversion 3.42
98 GA[2] Out Port A Green Channel Bit[7:2] 0.61
99 GA[3] Out Port A Green Channel Bit[7:2] 0.61
100 GA[4] Out Port A Green Channel Bit[7:2] 0.58
101 GA[5] Out Port A Green Channel Bit[7:2] 0.52
102 GA[6] Out Port A Green Channel Bit[7:2] 0.22
103 GA[7] Out Port A Green Channel Bit[7:2] 0.07
104 VDDP PI Digital Output Power 3.42
105 GND Gnd Digital Output Ground 0
106 GPO0 Out TCON GPO[9:0] 1.74
107 GPO1 Out TCON GPO[9:0] 0.09
