AlpsAV Soft-Touch Wall Mount - Product Dimension

PRODUCT DIMENSIONS AV02
Alps AV
Austria | Netherlands | USA: Nevada & New York | Hong Kong | Vietnam
www.AlpsAV.com
EU USA
+1 800 363 2918
+43 5572 535 30-3
contact@AlpsAV.com
FRONT VIEW LANDSCAPE ADAPTOR
VESA 600mm X 400mm
FRONT VIEW PORTRAIT ADAPTOR
VESA 400mm X 600mm
18.4’’
468mm
FRONT SIDE VIEW OPEN SIDE VIEW CLOSED
15.75’’
400mm
23.6’’
600mm
15.75’’
400mm
23.6’’
600mm
20.9’’
531mm
22.6”
574.5mm
9.8’’ (+/-0.3)
295mm (+/-10mm)
3.9’’ (+/-0.3)
100 mm (+/-10mm)
