AlpsAV Soft-Touch Wall Mount - Page 3

AlpsAV.com
3
INTERFACE KIT
REF INTERFACE KIT QTY REF INTERFACE KIT QTY
M6 x 16mm Screw
M6 x 25mm Screw
M6 x 40mm Screw
M8 x 16mm Screw
M8 x 25mm Screw
M8 x 40mm Screw
A 4
B 4
C 4
D
E
F
4
4
4
M8 x 5mm Spacer
M8 x 13mm Spacer
M6 washer (for parts A-C)
M8 washer (for parts D-F)
M8 x 25mm Spacer
G 4
H
J
K
4
4
4
I 4
A
B
C
D
E
F
G
H
I
J
K
