6490009ENLZ / 6790009ENLZ
►
5
◄
Al
sipercha with housing tube Alsipercha System
HARNESS EXTENSION
Description: Component joining the worker to
the retractable device.
code dimensions (mm) weight (kg)
84423 1.500 0.31
84474 500 0.15
ALSIPERCHA BODY
Description: Inverted “L” shaped unit, anchored
in the column with a working radius of 6.5 m that
allows access to a surface area of 125 m
2
.
code dimensions (mm) weight (kg)
84411 2,500 x 4,300 80
HOOK
Description: Component used to bring the
Alsipercha fall arrest system closer to the
worker when changing the anchorage.
code dimensions (mm) weight (kg)
83418 140 x 2,850 2
SLING
Description: An essential component used to
move the assembly with a crane, to take it to the
column, or remove it once the work is complete.
code dimensions (mm) weight (kg)
84414 3,000 0.62
LEVELLER
Description: Component that is introduced
into the housing tube, in order to ensure its
verticality and prevent the Housing Tube from
rising under the pressure of the concrete.
code dimensions (mm) weight (kg)
83416 1,005 x Ø70 3.96
HOUSING TUBE
Description: Component that is sunk into the
concrete column and houses the Alsipercha fall
arrest system.
code dimensions (mm) weight (kg)
84410 873 x Ø76 2.71
RETRACTABLE DEVICE
Description: Fall arrest block that stops in case
of fall.
code dimensions (mm) weight (kg)
8441201 2,500 1.599
84439 3,500 1.850
HARNESS
Description: Device anchoring the worker to the
Alsipercha fall arrest system.
code dimensions (mm) weight (kg)
84415 500 x 150 1
Component Description
Info
. In all codes the second digit can be either 3, 4, or 7.
CARABINER-EN 362
Description: connects SRL to Alsipercha and
harness extension to the user harness
code dimensions (mm) weight (kg)
8341203 100 0.50
