Description and operation
General description of the circuit--breaker
L12--0012EN/01
1/6
11--2012
© ALSTOM 2010. All rights reserved. Information contained in this doc ument is indic ative only. No representation or warranty is given or should be relied on
that it is complete or correct or will apply to any particular project. This will depend on the technical and commercial circumstances. It is provided without
liability and is subject to change without notice. Reproduction, use or disclosure to third parties, without express written authority, is strictly prohibited.
GRID
Circuit--breaker GL317X with spring o p erating mechanism FK3--5
Description
The circuit--breaker is made up of three poles, each activated by a spring
operating mechanism.
Diagram
A
C
B
D
Parts table
The table below gives the main parts of the circuit--breaker :
Mark Component Page
A Pole of the circuit--breaker 2
B Bearing structure 3
C Operating device 4
D Marshalling cubicle 5
