tab. B - TABLE OF SETTINGS
CONTROL MATRIX DIGITAL
INPUTS
DESCRIPTION FUNCTION 1 2 3
input enabled by normal de-energizing
first underresistance threshold trip lock BLOC. R<
sec. underresistance threshold trip lock BLOC. R<<
overcurrent threshold trip lock BLOC. I~>
overvoltage threshold trip lock BLOC. U~>
undervoltage threshold trip lock BLOC. U~<
first dir. undervolt. threshold trip lock BLOC.U-<
sec. dir. undervolt. thr. trip lock BLOC.U-<<
first dir. overvolt. threshold trip lock BLOC.U->
sec. dir. overvolt. threshold trip lock BLOC.U->>
timer tX1 start t_X1
timer tX2 start t_X2
timer tX3 start t_X3
switching to spare settings SETTINGS SWITCH / /
reset LED's and output relays RESET (LED+Xmem) / / X
WARNING:
The factory settings may prove not to suit the system. Therefore, the device must be configured anew upon installation
/ not to be allocated
X allocated
