V1 JUIN 2010 ALTECH Generation ALL IN ONE Type Heat Pump Water Heater Technical Manual
10
Running Operation
Auto/Manual start up, Energy-saving, standard, Enhanced
heating type heating water
Protection Method
High-pressure protection, Over-load protection,
Temp protection, Electric leakage protection
Dimension (D*H) mm Φ650×1920
Packing (W*H*D) mm 745*2030*775
Outdoor unit
Net/Gross weight kg 113 /129
Refrigerant type/Quantity Kg R134a/1.2
Operating pressure (refrigerant) MPa 3.0/1.2
Tank pressure Mpa 0.15/0.7
Tank Foaming Material/Depth(mm) polyurethane/55mm
Ambient temp ℃ -30~43
Diameter, water inlet pipe mm DN20
Diameter, water outlet pipe mm DN20
Diameter, drainage pipe mm DN20
Diameter, PT valve joint mm DN20
PT valce Brand Watts (active condition 99℃ or 0.7Mpa )
Rated pressure MPa 1.2
Max. Operation pressure MPa 0.7
Water outlet Temp ℃ (default) 55℃, 38℃℃60℃
water
pipeline
Heat exchanger Copper tube wrapped around outside of tank
Diameter, water inlet pipe
mm
DN20
Diameter, water outlet pipe mm DN20
Heat exchanger Surface heat exchanger; Stailess steel SUS304
heat exchanger tupe Dim.*Length mm Φ22*10000
heat exchanger area m2 0.7
Solar heat
exchanger
pipeline
Max.pressure MPa 0.7
Power wiring
mm2
2.5
Connection
wiring
Signal wiring
mm2
0.75
Fresh Air Diameter
mm
190.0
static pressure
Pa
30.0
Fresh air
Max Length
m
10.0
Hot Water Yield m3/h 0.075 0.075 0.064
Electric Heater kW 3.0
Remark:
1. The test conditions: outdoor temp. 15/12℃(DB/WB), inlet water temp. 15℃, outlet water temp. 45℃.
2. The operation range:-30℃-43℃, heat pump operation range: -7℃-43℃
3. The specification may be changed for product improvement, please refer to the nameplate.
