Altech BT300i User Manual

V1 JUIN 2010 ALTECH Generation ALL IN ONE Type Heat Pump Water Heater Technical Manual
9
1. Specifications
Model BT300i
Running Models
Economy Hybrid E-heater
Running Ambient temp. ℃ -7~43 -30~43 -30~43
Power supply ph-V-Hz
220~240V-1ph-50Hz
Storage size Ltr 300
Capacity KW 3.00 3.00 3.00
Input KW 0.83 0.83 3.00
Cop W/W 3.60 3.60 1.00
Rated current A 3.00 3.00 3.00
Testing Condition
Economy: A15/12 W15/45, setting Economy Mode;
Hybrid: A15/12 W15/45, setting Hybird Mode;
E-heater: A15/12 W15/45, setting E-heater Mode;
Max. Input KW 1.50 4.30 3.00
Max. Current A 6.50 18.7 13
Water
Heating
Nonimal
Testing Condition
Economy: A 43 W65, setting Economy Mode;
Hybrid: A 10 W60, setting Hybird Mode;
E-heater: A15 W70, setting E-heater Mode;
Max. Input KW 4.3
Max. current A 18.7
Starting current A 49.0
Model RB233GRDC
Type Rotary
Brand Guangzhou Mitsubishi electric
Supplier Guangzhou Mitsubishi electric
Capacity Btu/h 9485
Input W 850
Rated current(RLA) A 4.3
Locked rotor Amp(LRA) A 30
Thermal protector ℃ 115
Capacitor uF 30
Crankcase W 25
Compressor
Refrigerant oil ml 520
Model YDK30-6R
Type AC Motor
Brand Welling
Insulation class B
Safety class IPX4
Input W 80
Rated current A 0.53
Capacitor uF 3.5
outdoor fan
motor
Speed(hi/lo) r/min 770/640/500
material ASG20
Type Centrifugal type
Pressure pa 30
Diameter mm 271
outdoor fan
Height mm 130
Number of rows 3
Tube pitch(a)x row pitch(b) mm 22*19.05
Fin spacing mm 1.5
Fin type Arc hydrophile seam punching fin
Tube outer dia.and type mm Ф8.0 innergroove tube
Coil length x height 482*352
outdoor coil
Number of circuits 4
Outdoor air flow (Hi/mid/lo) m3/h 500/450/400
Noise level dB(A) 48
