AlteredStates BT Pro - Diagram

5
DIAGRAM
1
2
3
4
5
6
7
8
9
10
11
12
13
1—Battery Level indicator
2—Frequency Output
3—Power Charger input
4—Intensity Level Indicator
5—Program Display
6—Type of Level indicator—kHz,
%, C°, F° etc
7—SELECT button
8—Main Power Switch
9—DOWN button
10—UP button
11—POWER ON/OFF button
12—Power Warning Sign
13—Timer Clock
