10. #852 AR-7E ROTISSERIE INSTALLATION/OPERATION/SERVICE MANUAL
SECTION 2 ROTISSERIE OPERATION SECTION 2
PRODUCT LOADING
STANDARD SPITS
Each of the seven rotisserie spits includes two welded prongs
on the square end and one welded, ridged prong on the
tapered end. Insert the two-prong, square end into
the two holes indicated on the disk assembly
drive wheel in the drawing. Insert the
tapered, ridged-prong end into the top
hole indicated on the opposite
side and maneuver until the
ridge catches in the hole.
OPTIONAL PIERCING SPITS/BASKETS
When optional spits are used, insert the spits
in the drive wheel as indicated in the
illustration.
IMPOR
TANT NOTE:
When using a partial quantity of standard or
optional spits, space the spits evenly as
possible around the drive wheel to
maintain balance and even rotation.
SPECIAL
ATTENTION:
A combination of
standard, piercing, and
basket spits can be
used at the same time
but NOT in every spit
insertion position.
The use of a spit in
every position will interfere
with the free rotation of the
baskets. Using a combination of spits
can only be accomplished at significantly
reduced rotisserie capacity.
