#852 AR-7E ROTISSERIE INSTALLATION/OPERATION/SERVICE MANUAL 27.
FULL ASSEMBLY SERVICE VIEW
PANEL, CONTROL SIDE ACCESS 1001585
GASKET, DOOR GS-25753
DOOR ASSEMBLY, NON-CONTROL SIDE 5001075
DOOR ASSEMBLY, CONTROL SIDE 5001202
PANEL, CONTROL OVERLAY PE-25869
PAN, GREASE DRIP 1001557
TRAY, GREASE DEFLECTION 1001555
PROBE ASSEMBLY 15892
DOOR HINGE, CONTROL SIDE 1002597
DOOR HINGE, NON-CONTROL SIDE (NOT SHOWN)1002596
PIN, DOOR, TOP PI-26350
PIN, DOOR BOTTOM PI-26352
DOOR MAGNET MA-25734
LAMP COVER 5001818
LAMP COVER SCREW SC-26029
RADIANT HEATERS SEE SERVICE VIEW 5
SERVICE VIEW 1:
BASKET, STAINLESS STEEL WIRE (OPTION) BS-26019
DRIVE, DISK 1001636
DRIVE, DISK SLAVE 1001636
DRIVE, DISK HUB, STAINLESS STEEL DV-25713
DRIVE SLAVE, DISK HUB, STAINLESS STEEL DV-26108
DRIVE SLAVE BRACKET WITH BEARING (NOT SHOWN) 5000967
DRIVE, TUBE ASSEMBLY 5000962
SCREW, ROUND HEAD SLOT 1/4-20 X 1/2 SC-2332
SPIT, ANGLED SI-25934
SPIT, PIERCING (OPTION) SI-25729
SERVICE VIEW 2 AND 3:
DOOR ASSEMBLY, CONTROL SIDE 5001699
DOOR ASSEMBLY, NON-CONTROL SIDE 5001700
DOOR PIN, 5/16" X 3" DOWEL, TOP PI-26350
DOOR PIN, 5/16" X 3" DOWEL, BOTTOM PI-26352
GASKET, DOOR GS-25753
INSULATION, FIBERGLASS, 1/2" X 24" X 48" IN-2003
PANEL, INTERIOR STAINLESS STEEL BACK 1002279
PANEL, EXTERIOR STAINLESS STEEL BACK 1002280
SCREW, HEX CAP, 5/16-18 X 1" SC-2191
SCREW, INSERT WITH SPRING LOADED BALL SC-25781
SCREW, NC PHIL TRUSS, 8-32 X 3/8" SC-22378
WASHER, DOOR SPACER, TOP 1003941
WASHER, DOOR SPACER, BOTTOM 1002143
WASHER, FLAT [*CT, M8] WS-22298
SERVICE VIEW 4 AND 4A:
DOOR ASSEMBLY, CONTROL SIDE 5001202
DOOR ASSEMBLY, NON-CONTROL SIDE 5001075
DOOR PIN, TOP PI-26350
DOOR PIN, BOTTOM PI-26352
GASKET, DOOR GS-25753
GLASS, INNER, CONTROL SIDE 5002276
GLASS, INNER, NON-CONTROL SIDE 5002301
GLASS, OUTER, CONTROL SIDE 5002294
GLASS, OUTER, NON-CONTROL SIDE 5002295
NUT, HEX JAM, 5/16-18 NU-25897
SCREW, HEX CAP, 5/16-18 X 1" SC-2191
SCREW, INSERT WITH SPRING LOADED BALL SC-25781
SCREW, NC PHIL TRUSS, 8-32 X 3/8" SC-22378
WASHER, DOOR SPACER 1003941
WASHER, DOOR SPACER, BOTTOM 1002143
WASHER, FLAT [*CT, M8] WS-22298
SERVICE VIEW 5:
AIR DUCT 1002068
AIR DUCT MOUNTING BRACKET 1002069
BEARING BRACKET ASSEMBLY 5000967
BLOWER COVER 5001074
BOARD, POWER SUPPLY, 12V DC, SWITCH BA-33554
CONTACTOR, 208/240V, 3 POLE 25 AMP (2) CN-3052
ELECTRICAL COMPONENT ASSEMBLY 5000950
ELEMENT, AIR HEAT, 5000 W EL-34106
ELEMENT, AIR HEAT, 240V, 5500W EL-34107
ELEMENT BRACKET, AIR HEAT 1003559
ELEMENT BRACKET, AIR HEAT 1003595
FAN, BLOWER MOTOR CAPACITOR, 4 UF FA-33931
FUSEHOLDER, 15A, CLASS G FU-3772
HEATER, CE (INTERNATIONAL ONLY) EL-33970
HEATER, 208V EL-33974
HEATER, 240V EL-33973
HEATER BAR BRACKET 1002455
HEATER COVER, RADIANT 1001948
LAMP, 250V-60W LP-33803
LAMP BULB, TUBULAR, 240V, 150W, CLEAR (4) LP-33513
LAMP COVER 5001818
LAMP RECEPTACLE RP-3952
MOTOR BLOWER SEAL, TEFLON® SA-25862
MOTOR BRACKET 1001578
MOTOR, CONVECTION FAN, 220-240V MO-33892
MOTOR DRIVE, 230V, AC MO-33893
MOTOR DRIVE SEAL, TEFLON® SA-25863
PLATE, HEATER MOUNTING 1002462
RELAY, POWER RL-33930
SCREW, CONVECTION COVER KN-26005
SCREW, NC PHIL TRUSS, 8-32-32-3/8 SC-22378
SCREW, #6-32 x 3/8 SC-23455
SCREW, #6-32 x 1-1/4 SC-2365
SENSOR, AMBIENT TEMPERATURE SN-33540
SENSOR CLIP 1002261
SENSOR GUARD 1002048
SWITCH, FAN SAIL SW-33907
SWITCH BRACKET, FAN SAIL 1001913
TERMINAL BLOCK BK-3597
ELECTRIC/ELECTRONIC:
CONTROL ASSEMBLY, ELECTRIC 5001238
CONTROL BEEPER BP-3567
CONNECTOR CR-33763
CONNECTOR CR-33761
CONNECTOR CR-33717
CONNECTOR CR-33719
PROBE PR-3945
RESISTOR, MOV, SURGE PROTECTOR RS-3578
TERMINAL BLOCK BK-3597
SWITCH, DOOR SW-33906
AR-7E ROTISSERIE ● SERVICE PARTS
PART DESCRIPTION PART NO. PART DESCRIPTION PART NO.
