#852 AR-7E ROTISSERIE INSTALLATION/OPERATION/SERVICE MANUAL 3.
SECTION 1 ROTISSERIE INSTALLATION SECTION 1
STACKING COMBINATIONS AND INSTALLATION REQUIREMENTS
AR-7VH VENTLESS HOOD
OVER AR-7E ROTISSERIE
requires 4" (102mm) legs for counter top applications.
Free standing floor installations require 6" (152mm) leg assembly 5001414 or 5" (127mm) casters 4007.
HxWxD = 54-1/2" x 37-15/16" x 34-7/8" (1430mm x 964mm x 885mm)
AR-7E ROTISSERIE OVER AR-7E ROTISSERIE
requires 6" (152mm) leg assembly 5001414 or 5" (127mm) casters 4007 and stacking assembly 5001479
for applications within the United States.
Applications outside the U.S. require 6" (152mm) legs with flanged feet 5001761 bolted to the floor.
HxWxD = 77-3/16" x 37-15/16" x 33" (1961mm x 964mm x 838mm)
AR-7H COMPANION HOLDING CABINET OVER AR-7E ROTISSERIE
requires 6" (152mm) leg assembly 5001414 or 5" (127mm) casters 4007 and stacking assembly 5001480
for applications within the United States.
Applications outside the U.S. require 6" (152mm) legs with flanged feet 5001761 bolted to the floor.
(
ROTISSERIE OVEN MUST BE BOLTED TO A NON-COMBUSTIBLE SURFACE).
HxWxD = 77-3/16" x 37-15/16" x 35-7/8" (1961mm x 964mm x 911mm)
AR-7E ROTISSERIE OVER AR-7H COMPANION HOLDING CABINET
requires 6" (152mm) leg assembly 5001414 or 5" (127mm) casters 4007 for applications within the
United States.
Applications outside the U.S. require 6" (152mm) legs with flanged feet 5001761 bolted to the floor.
HxWxD = 74-3/4" x 37-15/16" x 33" (1898mm x 964mm x 838mm)
AR-7VH VENTLESS HOOD OVER AR-7E ROTISSERIE OVER AR-7H COMPANION HOLDING CABINET
requires 6" (152mm) legs with flanged feet 5001761 bolted to the floor.
HxWxD = 91-1/4" x 37-15/16" x 34-7/8" (2298mm x 964mm x 885mm)
TO A
VOID TIPPING
OUTSIDE THE U.S.A., ALL STACKED
COMBINATIONS OF ROTISSERIES AND
WARMERS MUST INCLUDE FLANGED FEET
AND MUST BE BOLTED TO THE FLOOR.
OPTIONS AND ACCESSORIES
Casters, 5" (127mm) . . . . . . . . . . . . . . . . . . . . . . . 4007
Custom Panel Colors . . . . . . . . . . . . . . . . FACTORY QUOTE
DOOR OPTIONS:
➥ Double Pane Curved Glass with Handle . . . 5001202
➥ Double Pane Curved Glass without Handle . 5001075
Door Handle (ON NON-CONTROL SIDE) . . . . . . . . . 5001087
Drip Pan with drain . . . . . . . . . . . . . . . . . . . . . 5001094
Legs, 6" (152mm) Assembly. . . . . . . . . . . . . . . 5001414
Legs, 6" (152mm) Assembly, flanged feet . . . . . 5001761
Multi-Purpose Wire Basket (.50 diameter pin) . . BS-26019
Probe, Internal Product Temperature. . . . . . . . . . . 15892
SPITS:
➥ Angled Spit, Stainless Steel . . . . . . . . . . . . SI-25934
➥ Piercing Spit, Stainless Steel . . . . . . . . . . . SI-25729
STACKING ASSEMBLY:
➥ AR-7E over AR-7E . . . . . . . . . . . . . . . . . . 5001479
➥ AR-7E over AR-7H . . . . . . . . . . . . . . NONE REQUIRED
➥ AR-7H over AR-7E . . . . . . . . . . . . . . . . . 5001480
STANDS:
➥ AR-7E over 6•10iN/ML, 36-13/16" (935mm) . 5001361
➥ AR-7E w/ Shelf, 36" (914mm) . . . . . . . . . 5002057
➥ AR-7E over 750-S, 36" (914mm) . . . . . . . 5002058
Teflon® Coated Accessories - COMMERCIAL GRADE
➥ Items purchased separately . . . . . . . . . . . . 5001302
Ventless Hood, FACTORY INSTALLATION ONLY . . . . . AR-7VH
