INSTALLATION
Ve ct or F ® Se ries ▪ O pera to r’s Man ual ▪ MN-468 94 ▪ Rev 1 ▪ 7/2 0
30
Continued from previous page
10. Connect the wires to the appropriate terminals (L1, L2, L3, etc.) of the main
disconnect switch
g in accordance with local codes and regulations.
Install the ground wire h to the ground terminal.
11. Re-install the main disconnect switch.
12. Re-install the 4 screws holding the main disconnect switch to the oven.
13. Re-install the terminal block assembly.
14. Tighten the cord grip sealing nut onto the supply cord.
15. Re-install the side panel.
16. Press and release the high limit temperature reset buttons i.
Remove the tag j.
Continued on next page
VMC-F3, VMC-F4
VMC-TS-009566
i
j
To Next Page
