COMPONENTS
Ve ctor F® Se ries ▪ S ervice Ma nual ▪ M N- 46 89 5 ▪ R ev 1 ▪ 7/ 20
36
Terminal Blocks
VMC-PHD-010716
1
2
3
4
5
6
7
8
Ref. Description
1 TB 67 Light 1
2 TB 69 Light 3
3 TB 63 Light 1
4 TB 65 Light 3
5 TB 68 Light 2
6 TB 70 Light 4 F4
7 TB 64 Light 2
8 TB 66 Light 4 F4
