ASSEMBLY/DISASSEMBLY
Ve ctor F® Se ries ▪ S ervice Ma nual ▪ M N- 46 89 5 ▪ R ev 1 ▪ 7/ 20
98
Continued from previous page
3. Remove the back panel c.
4. Disconnect the fan wire connector d.
Disconnect the blower motor wire connectors e.
5. Cut the insulation around the motor.
Loosen the motor mount adjustment screws f.
Continued on next page
VMC-TS-010672
c
VMC-TS-003702
d
e
VMC-TS-003705
f
