INSTALLATION
Vecto r H® S eries ▪ Operat or’s M anual ▪ M N-46 2 95 ▪ Rev 7 ▪ 6/22
31
Continued from previous page
8. Install the ground wire f.
Adjust the cord length.
Tighten the cord grip sealing nut onto the supply cord.
9. Re-install the main disconnect switch.
10. Re-install the mounting bracket.
11. Re-install the top cover.
Press reset button(s) 12. Press and release the high limit temperature reset button(s) g.
Remove the tag h.
Result The oven is now installed.
VMC-TS-001829
f
VMC-TS-007949
LA-39715
VMC-H2, VMC-H3, VMC-H4
VMC-H2H, VMC-H3H, VMC-H4H
h
g
