INSTALLATION
Vecto r H® S eries ▪ Opera tor’s Manual ▪ M N-462 9 5 ▪ Rev 7 ▪ 6/22
50
Continued from previous page
5. Follow the steps below and inspect the installation of the jet plates.
▪ Make sure the ∞ symbols are aligned.
▪ Make sure the fork and knife arrows point to the product in each
chamber.
▪ On later production jet plates which include a “W” etched into them,
make sure the “W” etched aligns with the “W” etched in the door frame.
Result The jet plates are now installed.
