Page -15-
WAP TECHNOLOGY Wet/Dry Vacuums Operator's Manual
SQ 10 &15 Gallon
Assembly Parts List 3/00
WAP TECHNOLOGY
Ref. Part No. Description Qty
1 47014 Ring, Foam Rubber 1
2 47006 Silencer 1
3 44239 Lower Housing, SQ. 1
4 26792 Ground Contact SQ. 10 1
5 11253 Screw, 50mm x 20mm 1
6 11222 Packing Ring, Gasket 1
7 11256 Screw, 35mm x 18mm 1
8 48421 Terminal Block 1
9 11835 Float, Short 1
10 45692 Deflector 1
11 46418 Filter Frame 1
12 11565 Screw, 50 x 18 1
13 29747 Fleece Filter, SQ. 1
14 47025 Covering 1
15 29753 Filter Holder Disc, SQ. 1
16 31972 Rubber Seal, Vac Motor 2
17 29739 Filter Bags, 10 Gallon
14896 Filter Bags, 15 Gallon
18 65243 Canister, SQ 10 Blue 1
100006 Canister, SQ 15 Blue 1
19 29191 Packing Ring SQ 1
20 26797 Clamp 2
21 43975 Retaining Pin (Wheel) 2
22 43435 Cap (Wheel) 2
23 43433 Wheel 2
24 46298 Cater Swivel
25 15102 Swivel, Hose 1
26 15805 Suction Hose 1.5" x 10' 1
27 11597 Hose Cuff 1
28 29758 Wand Bracket Set 1
29 5103 Curved Wand, Chrome 1
30 15546 Straight Wand EXT. (2 Pcs.) 1
31 26774 Carbon Brush (Pair) 1
32 26785 Vac, Motor Complete 1
33 47035 Rubber Seal, Vac Motor 1
34 44240 Upper Housing, SQ 1
35 47015 Motor Ring 1
36 25700 Air Diverter, SQ. 1
37 29989 Rotary Switch, SQ. 1
38 48338 Screening Filter 1
39 29755 Control Panel 1
40 46297 Plug Cover 1
41 46248 Screw 1
42 49267 Plug Socket 1
43 243606 Knob, SQ. 1
44 9868 O Ring 10 x 2.5 mm 1
45 18274 Screw
46 11254 Screw
47 26801 Handle 1
48 26803 Cover SQ. 1
