Page -17-
WAP TECHNOLOGY Wet/Dry Vacuums Operator's Manual
SQ 17 Gallon
Assembly Parts List 3/00
WAP TECHNOLOGY
Ref. Part No. Description Qty
1 5103 Curved Wand, Chrome
2 5067 Rubber Nozzle
3 47429 Filter Bag, SQ. 17 (5 pcs.)
4 15365 Hose, Vac 13' x 36 mm 1
5 11597 Hose Cuff 1
6 15102 Swivel, Hose 1
7 60738 Belt, Front 1
8 60737 Belt, Rear 1
9 17847 Screw, 6mm x 20mm
10 17849 Washer, 6.4 x 1.6
11 11565 Screw, 50 x 18
12 46073
13 46223
14 29191 Packing Ring SQ 1
15 19880 Clamp 2
16 15889 Rivet 4
17 60739 Canister 17 Gal. 1
18 46134 Handle Bar SQ. 1
19 17737 Screw, Countersunk
20 12496 Nut
21 60767 End Cap 2
22 60746 Panel, Side R.H. 1
23 60771 Screw, Self Threading 4
24 60744 Panel, Side L.H. 1
25 7895 End Cap, Carriage Frame 2
26 60741 Frame 2
27 46301 Bracket, Frt. Carriage 1
28 2758 Nut M8 1
29 30738 Screw, M8 x 30
30 11474 Caster, Locking 2
31 46490 Cap, Wheel 2
32 48647 Wheel 2
33 29753 Filter Holder Disc 1
34 47025 Covering 3
35 29747 Fleece Filter 1
Ref. Part No. Description Qty
36 11565 Screw, 50 x 18
37 46418 Filter Frame 1
38 45692 Deflector 1
39 11835 Float, Short 1
40 11222 Packing Ring Gasket 1
41 11253 Screw, 50 x 20
42 26792 Ground Contact 1
43 44239 Lower Housing 1
44 48414 Plug 2
45 46640 Washer
46 47014 Foam Ring 1
47 28875 Motor Seal 2
48 26774 Carbon Brushes (Pair) 1
49 26785 Vacuum Motor Complete 1
50 47036 Rubber Ring 1
51 5697 Strain Relief 1
52 11256 Screw 35 x 18
53 48421 Terminal Block 1
54 44240 Upper Housing SQ 1
55 60285 Power Cord 1
56 25700 Air Diverter 1
57 24738 Screw
58 29989 Rotary Switch 1
59 48338 Screening Filter 1
60 29755 Control Panel 1
61 11254 Screw
62 18274 Screw
63 9868 O Ring 10 x 2.5 1
64 243606 Knob, SQ. 1
65 46297 Plug Cover, SQ 1
66 49267 Plug Socket 1
67 46428 Screw
68 26801 Handle SQ. 1
69 26803 Cover SQ. 1
70 10029 EJOT - Screw 5.0 x 25
