Alto AMX-100 Service Manual

Multi-Level BOM Structure Listing
Report No.:
Prepared by
020050[賴玉菁]
2004/12/03
Date
Page No.:
4
/
18
IEBO_P02
SEKAKU ELECTRON INDUSTRY (H.K.) CO.,LTD
Version UNIT:
PF01441
AMX-100FX
AMX-100FX_ALTO_230V
PCS
2003/12/17
Date:DESCRIPTION:
Item No.
Version Item No
Item Descri
Ver. UnitLoss %
Cardinal
@:Phantom Layer
Effective Date
Component Remark
Usage Rate
Attrition Rate
││
2.0000
1L.E.D high intensity
3m/m round(yellow)long foot 26
SA00054│├0013-------------------------------
││
0.00
%
N
││
PCS
2003/12/24
││ LD13,LD14
││
15.0000
1LED spacer support
LEDS-11 11mm
NI01782│├0014-------------------------------
││
0.00
%
N
││
PCS
2003/12/24
││ LD1,LD2,LD3,LD4,LD7,LD8,LD9,LD10,LD11,LD12,LD13,LD14,
││ LD15,LD16,LD17
││
1.0000
1relay
RY-5W-K,5V
HI00161│├0015-------------------------------
││
0.00
%
N
││
PCS
2003/12/24
││ RL1
││
2.0000
1row-wire header(male)
2P 2.5mm 90°
HC00065│├0016-------------------------------
││
0.00
%
N
││
PCS
2003/12/24
││ SW10,SW11
││
1.0000
1push-button switch
2 stage 6P PS-9226A(NON-LOCK)
HI00238│├0017-------------------------------
││
0.00
%
N
││
PCS
2003/12/24
││ SW9
││
2.0000
1push-button switch
2-stage 6P PS-9226A(SELF-LOCK)
HI00236│├0018-------------------------------
││
0.00
%
N
││
PCS
2003/12/24
││ SW1,SW2
││
1.0000
1integrated circuit
L7805CV(TO-220)(ST)
SD00074│├0019-------------------------------
││
0.00
%
N
││
PCS
2003/12/24
││ TR20
││
1.0000
1integrated circuit
L7815CV(TO-220)(ST)
SD00077│├0020-------------------------------
││
0.00
%
N
││
PCS
2003/12/24
││ TR21
││
1.0000
1integrated circuit
L7915CV(TO-220)(ST)
SD00079│├0021-------------------------------
││
0.00
%
N
││
PCS
2003/12/24
││ TR22
││
1.0000
1transistor
TIP122(ST)
SB00043│├0022-------------------------------
││
0.00
%
N
││
PCS
2003/12/24
││ TR23
││
2.0000
1integrated circuit
BA15218N (M5218L substitute)
SD00007│├0023-------------------------------
││
0.00
%
N
││
PCS
2003/12/24
││ U22,U23
││
2.0000
1potentiometer
Z10KΩ RD09F1130042-10KZ(SAS1);30F
RC00356│├0024-------------------------------
││
0.00
%
N
││
PCS
2004/06/12
││ VR1,VR2
││
