Alto AMX-100 Service Manual

Multi-Level BOM Structure Listing
Report No.:
Prepared by
020050[賴玉菁]
2004/12/03
Date
Page No.:
8
/
18
IEBO_P02
SEKAKU ELECTRON INDUSTRY (H.K.) CO.,LTD
Version UNIT:
PF01441
AMX-100FX
AMX-100FX_ALTO_230V
PCS
2003/12/17
Date:DESCRIPTION:
Item No.
Version Item No
Item Descri
Ver. UnitLoss %
Cardinal
@:Phantom Layer
Effective Date
Component Remark
Usage Rate
Attrition Rate
6.0000
1SMD fixed resistor 1/10W
1.1KΩ ±5% 0603
RD00350│││├0021---------------------------
││││
0.00
%
N
││││
PCS
2003/12/17
││││ R63,R64,R81,R82,R212,R213
││││
6.0000
1SMD fixed resistor 1/10W
1.3KΩ ±5% 0603
RD00351│││├0022---------------------------
││││
0.00
%
N
││││
PCS
2003/12/17
││││ R108,R109,R110,R111,R137,R139
││││
4.0000
1SMD fixed resistor 1/10W
1.5KΩ ±5% 0603
RD00085│││├0023---------------------------
││││
0.00
%
N
││││
PCS
2003/12/17
││││ R147,R148,R264,R265
││││
3.0000
1SMD fixed resistor 1/10W
2.0KΩ ±5% 0603
RD00087│││├0024---------------------------
││││
0.00
%
N
││││
PCS
2003/12/17
││││ R244,R177,R180
││││
2.0000
1SMD fixed resistor 1/10W
3.6KΩ ±5% 0603
RD00352│││├0025---------------------------
││││
0.00
%
N
││││
PCS
2003/12/17
││││ R230,R231
││││
6.0000
1SMD fixed resistor 1/10W
3.9KΩ ±5% 0603
RD00092│││├0026---------------------------
││││
0.00
%
N
││││
PCS
2003/12/17
││││ R87,R88,R89,R90,R256,R257
││││
5.0000
1SMD fixed resistor 1/10W
4.7KΩ ±5% 0603
RD00093│││├0027---------------------------
││││
0.00
%
N
││││
PCS
2003/12/17
││││ R97,R98,R124,R248,R249
││││
21.0000
1SMD fixed resistor 1/10W
6.8KΩ ±5% 0603
RD00097│││├0028---------------------------
││││
0.00
%
N
││││
PCS
2003/12/17
││││ R104,R105,R112,R113,R114,R115,R116,R117,R118,R119,
││││ R120,R121,R150,R151,R152,R154,R155,R156,R254,R284,R288
││││
6.0000
1SMD fixed resistor 1/10W
7.5KΩ ±5% 0603
RD00098│││├0029---------------------------
││││
0.00
%
N
││││
PCS
2003/12/17
││││ R19,R20,R21,R22,R238,R239
││││
2.0000
1SMD fixed resistor 1/10W
33KΩ ±5% 0603
RD00108│││├0030---------------------------
││││
0.00
%
N
││││
PCS
2003/12/17
││││ R203,R204
││││
9.0000
1SMD fixed resistor 1/10W
20KΩ ±5% 0603
RD00306│││├0031---------------------------
││││
0.00
%
N
││││
PCS
2003/12/17
││││ R5,R12,R122,R123,R125,R126,R192,R193,R195
││││
2.0000
1SMD fixed resistor 1/10W
22KΩ ±5% 0603
RD00105│││├0032---------------------------
││││
0.00
%
N
││││
PCS
2004/04/30
││││ R131,R132
││││
