Alto AMX-100 Service Manual

Multi-Level BOM Structure Listing
Report No.:
Prepared by
020050[賴玉菁]
2004/12/03
Date
Page No.:
11
/
18
IEBO_P02
SEKAKU ELECTRON INDUSTRY (H.K.) CO.,LTD
Version UNIT:
PF01441
AMX-100FX
AMX-100FX_ALTO_230V
PCS
2003/12/17
Date:DESCRIPTION:
Item No.
Version Item No
Item Descri
Ver. UnitLoss %
Cardinal
@:Phantom Layer
Effective Date
Component Remark
Usage Rate
Attrition Rate
1.0000
1SMD fixed resistor 1/10W
5.6KΩ ±5% 0603
RD00095│││└0057---------------------------
│││
0.00
%
│││
PCS
2004/09/14
│││ R446
│││
1.0000
1jumper wire
8mm
HA01922││├0005-----------------------------
││││
0.00
%
││││
PCS
2004/05/07
││││ J34
││││
0.0180
1wire
φ0.6
HA02249│││└0001---------------------------
│││
0.00
%
N
│││
M
KG
2004/08/05
4.0000
1electrolytic capacitor
2.2uF/50V φ5*11mm
CB00239││├0006-----------------------------
│││
0.00
%
│││
PCS
2004/08/30
│││ C136,C137,C195,C196
│││
3.0000
1electrolytic capacitor
4.7uF/100V φ5*11mm
CB00240││├0007-----------------------------
│││
0.00
%
│││
PCS
2004/08/30
│││ C221,C222,C223
│││
4.0000
1electrolytic capacitor
22uF/35V φ5*11mm
CB00242││├0008-----------------------------
│││
0.00
%
│││
PCS
2004/08/30
│││ C15,C16,C18,C19
│││
59.0000
1electrolytic capacitor
47uF/25V φ5*11mm
CB00194││├0009-----------------------------
│││
0.00
%
│││
PCS
2004/09/13
│││ C17,C20,C55,C56,C57,C58,C59,C60,C61,C62,C63,C64,C65,
│││ C66,C67,C68,C69,C70,C71,C72,C73,C74,C75,C76,C77,C78,
│││ C79,C80,C81,C82,C83,C84,C85,C86,C87,C88,C89,C90,C91,
│││ C92,C93,C94,C95,C96,C97,C98,C99,C100,C101,C102,C103,
│││ C104,C105,C190,C191,C233,C403,C404,C410
│││
4.0000
1electrolytic capacitor
47uF/100V φ10*12mm 5mm
CB00254││├0010-----------------------------
│││
0.00
%
│││
PCS
2004/08/30
│││ C401,C402,C406,C407
│││
12.0000
1metal-film capacitor MSC
0.012uF/63V ±5% CASE01
CF00138││├0011-----------------------------
│││
0.00
%
│││
PCS
2004/08/30
│││ C51,C52,C53,C54,C130,C133,C134,C135,C155,C156,C171,
│││ C172
│││
12.0000
1metal-film capacitor MSC
0.018uF/63V 5% CASE01
CF00136││├0012-----------------------------
│││
0.00
%
│││
PCS
2004/08/30
│││ C37,C39,C40,C41,C47,C48,C49,C50,C131,C132,C163,C164
│││
12.0000
1metal-film capacitor MSC
0.033uF/63V 5% CASE01
CF00137││├0013-----------------------------
│││
0.00
%
│││
PCS
2004/08/30
│││ C114,C115,C124,C125,C126,C127,C128,C129,C139,C140,
│││ C141,C142
│││
4.0000
1rectifier diode
1N4002/100V
SA00094││├0014-----------------------------
│││
0.00
%
│││
PCS
2004/08/30
│││ D12,D13,D14,D15
