Alto AMX-100 Service Manual

Multi-Level BOM Structure Listing
Report No.:
Prepared by
020050[賴玉菁]
2004/12/03
Date
Page No.:
16
/
18
IEBO_P02
SEKAKU ELECTRON INDUSTRY (H.K.) CO.,LTD
Version UNIT:
PF01441
AMX-100FX
AMX-100FX_ALTO_230V
PCS
2003/12/17
Date:DESCRIPTION:
Item No.
Version Item No
Item Descri
Ver. UnitLoss %
Cardinal
@:Phantom Layer
Effective Date
Component Remark
Usage Rate
Attrition Rate
1.0000
1PC board
P-313123-AI(L-8)
HK04041│├0004-------------------------------
│││
0.00
%
│││
PCS
2003/12/16
1.0000
1PC board
P-313123-SMD(L-8)
HK03894││├0001-----------------------------
││││
0.00
%
N
││││
PCS
2003/06/18
1.0000
1PCB
313123/2(1*6)
HB00895│││├0001---------------------------
││││
0.00
%
N
││││
PCS
2003/04/29
2.0000
1SMD ceramic capacitor 0603
15PF/50V NPO ±5%
CI00049│││├0002---------------------------
││││
0.00
%
N
││││
PCS
2003/04/29
││││ C8,C9
││││
13.0000
1SMD ceramic capacitor 0603
0.1uF/50V Y5V +80,-20%
CI00075│││├0003---------------------------
││││
0.00
%
N
││││
PCS
2003/04/29
││││ C17,C15,C18,C6,C10,C22,C20,C13,C14,C1,C3,C4,C11
││││
1.0000
1SMD fixed resistor 1/10W
10Ω ±5% 0603
RD00061│││├0004---------------------------
││││
0.00
%
N
││││
PCS
2003/04/29
││││ R22
││││
8.0000
1SMD fixed resistor 1/10W
100Ω ±5% 0603
RD00068│││├0005---------------------------
││││
0.00
%
N
││││
PCS
2003/04/29
││││ R12,R14,R7,R8,R34,R17,R13,R33
││││
1.0000
1SMD fixed resistor 1/10W
220Ω ±5% 0603
RD00073│││├0006---------------------------
││││
0.00
%
N
││││
PCS
2003/04/29
││││ R3
││││
10.0000
1SMD fixed resistor 1/10W
1.5KΩ ±5% 0603
RD00085│││├0007---------------------------
││││
0.00
%
N
││││
PCS
2003/04/29
││││ R16,R15,R21,R20,R4,R19,R10,R18,R9,R5
││││
8.0000
1SMD fixed resistor 1/10W
2.2KΩ ±5% 0603
RD00088│││├0008---------------------------
││││
0.00
%
N
││││
PCS
2003/04/29
││││ R28,R27,R23,R24,R29,R30,R25,R26
││││
3.0000
1SMD fixed resistor 1/10W
10KΩ ±5% 0603
RD00101│││├0009---------------------------
││││
0.00
%
N
││││
PCS
2003/04/29
││││ R32,R31,R1
││││
1.0000
1SMD fixed resistor 1/10W
1.0MΩ ±5% 0603
RD00125│││├0010---------------------------
││││
0.00
%
N
││││
PCS
2003/04/29
││││ R2
││││
2.0000
1SMDrow resistor1/16W
100Ω*4 ±5% 8P 0603
RE00006│││├0011---------------------------
││││
0.00
%
N
││││
PCS
2003/04/29
││││ AR1,AR2
││││
1.0000
1SMD rectifier diode
RLS4148 0.5A (LL-34)
SE00011│││├0012---------------------------
││││
0.00
%
N
││││
PCS
2003/04/29
││││ D1
