Alto LYNX-MIX62 Service Manual

6 CHANALE MIXER
Microphone Input Electronically Balanced, Discrete Input Configuration
Frequency Response 20Hz to 22kHz, +/-3dB
Distortion( THD&N)
＜0.01% At + 4dBu, 1kHz
Gain range 0 dB to 50 dB (MIC)
70 dB CH MIC INPUT→MAIN OUT(Unbalanced)
80 dB CH MIC INPUT→CTRL ROOM OUT
80 dB CH MIC INPUT→HEAD PHONE OUT
70 dB CH MIC INPUT→TAPE OUT
60 dB CH MIC INPUT→AUX1 OUT
70 dB CH MIC INPUT→AUX2 OUT
20 dB AUX RETURN→MAIN OUT(Unbalanced)
10 dB AUX RETURN→AUX1 OUT
20 dB TAPE INPUT→MAIN OUT(Unbalanced)
SNR( Signal to Noise Rate) 114 dB
Line Input Electronically Balanced
Frequency Response 20Hz to 22kHz, +/-3dB
Distortion( THD&N)
＜0.01% At + 4dBu, 1kHz
Gain range
15 dBu to 35 dBu(CH1~CH2),20 dBu to -20
dBu(CH3~CH4)
55 dB CH LINE INPUT→MAIN OUT(Unbalanced)
65 dB CH LINE INPUT→CTRL ROOM OUT
65 dB CH LINE INPUT→HEAD PHONE OUT
55 dB CH LINE INPUT→TAPE OUT
45 dB CH LINE INPUT→AUX1 OUT
55 dB CH LINE INPUT→AUX2 OUT
40 dB CH LINE INPUT→MAIN OUT(Unbalanced)
50 dB CH LINE INPUT→CTRL ROOM OUT
50 dB CH LINE INPUT→HEAD PHONE OUT
40 dB CH LINE INPUT→TAPE OUT
30 dB CH LINE INPUT→AUX1 OUT
40 dB CH LINE INPUT→AUX2 OUT
Microphone Input 1.4k Ohms
Channel Insert return 2.5k Ohms
All Other Input 10k Ohms or Greater
Tape Out 1k Ohms
Input Channels
(MAIN OUT)
Type
LYNX-MIX 62/62FX
Impedance
Maximum Voltage Gain
Maximum Voltage Gain
(Mono Channel )
Maximum Voltage
Gain(Stereo Channel )
2. Specification
--- 2 ---
