Alto MAC 2.3 - Schematic Diagrams

STEREO MODE
HOOK
UP
In this mode, 2 independent channels are sent to 2 separate speakers.
PARALLEL MODE
HOOK
UP
One mono signal is input to channel 1 or Channel 2 of the MAC 2 series
amplifier and then output to 2 separate speakers. Each speaker volume
can be set separately.
3
POWER
ON
OFF
MAC 2.4
StereoPower Amplifier
LTO
R
CLIP
SIG
PROT
POWER
CH1 CH2
POWER
ON
OFF
MAC 2.4
StereoPower Amplifier
LTO
R
CLIP
SIG
PROT
POWER
CH1 CH2
