Alto MACRO 830 User Manual

5.2 Operate MACRO 830/1400/2400 in Parallel (Mono) Mode
In this mode, the Channel A input signal will be output from the output connectors of both Channels. The Channel
B input jack is not used, the Channel A and B volumes can be adjusted independently.
