3. CONTROL ELEMENTS
SPOTLIGHT
4
14
MODE SELECTOR
The MISTRAL stereo power amplifiers present two operating modes:
- Stereo Mode
In this mode, CH 1 and CH 2 operate independently (as a normal stereo amplifier).
The CH 1 input signal will be output from the CH 1 output connector, and CH 2
input signal will be output from the CH 2 output connector.
- Bridge Mode
In this mode, CH 1 input signal will be output from the bridge-mono output connector.
On the other hand, the output level control of CH 2 should be turn to the minimum.
12
BALANCED INPUT CONNECTOR
These connectors connect the input signal of CH 1 and CH 2 separately.
13
BALANCED OUTPUT CONNECTOR
These two output connectors are parallelled inside with input connectors. It enables
the unit work under parallelled mode. Please also refer to wiring diagram for paralleled
mode.
11
LIMITER SWITCH
Set the switch at "ON" position, once the output level is above maximum, the clip
begins, thus keeping consistent output level for protecting apparatus. If the
switch is set at "OFF" position, this clip function doesn't work.
