Alto MISTRAL 6000 Service Manual

No Part No. Description Specification Qty.
1 MA04305 ZC-Panel MISTRAL6000 ALTO-V1.0 1
2 MA00028 ZC-Panel MISTRAL6000 ALTO-V1.0 1
3 MB03701 ZC-Chassis MISTRAL6000 V-1.1 1
4 MC00636 ZC-Top cover MISTRAL6000 V-1.1 1
5 MI02404 ZB-handle MISTRAL6000 20*25.5*124V1.0 2
6 MI02399 ZB-Fixed bracket MISTRAL6000 L V1.0 1
7 MI02397 ZB-Fixed bracket MISTRAL6000 R V1.0 1
8 MI02401 ZB-Front panel MISTRAL6000 V1.0 1
9 MI02409 ZB-Barrier board MISTRAL6000 122.5*70.1*66.1 1
10 MI02407 ZB-Iron board MISTRAL6000 422*14*2.0t_V1.0 2
11 MI02411 ZB- Barrier board MISTRAL6000 422*14*66.1R-V1.0 1
12 NI02650 Plastic knob
φ18*18mm
2
13 NI02651 Fixed sleeve knob
10*φ22.5
2
14 NI02853 Bushing
7P-2 SIZE ψ 11.0 SJT3C#14
1
15 HI00022 Power switch 4P R13-69A 1
16 MF00020 Color washer
φ5*φ12*1t
4
17 MF00039 Washer
φ5*φ8*1t
4
18 MG00247 Copper pillar M3*10*0.5PH 4
19 MG00061 Screw M3*10 10
20 MG00295 Screw M4*6 12
21 MG00025 Screw M3*6 23
22 MF00042 Screw M3*10 10
23 MF00037 Washer
φ3*φ5*1t
14
24 ME00015 Color nut 3mm 8
25 MF00038 Washer
φ4*φ7*1t
7
26 ME00016 Color nut 4mm 3
27 MF00048 Locking
φ4*φ8*0.5t
1
28 MF00018 Color washer
φ4*φ10*1t
6
29 MG00041 Screw M3*6 8
30 MG00075 Screw M4*16 4
31 ME00006 Nut
φ9
2
32 MF00004 Color washer
φ9*φ14*0.5t
2
33 MG00437 Rubber coil
φ20*φ120*2tB
1
34 MG00520 Screw M8*115*1.25PH_V1.0 1
35 ME00026 Zi-nut M8 1
36 MF00026 Color washer
φ8*φ18*1.5t
1
37 MF00041 Washer
φ8*φ13.5*2t
1
38 MH00766 ZB-iron
φ11*φ90*2_v1.1
1
39 TD00302 Loop transformer PT-MIS6000_115/230V 1
40 NI00312 SW button 5*5*9 2.8*2.8 2
41 HA03442 Bushing LT-322+1.5*3C(G05VV-F)2.27M BK 1
42 NC00059 ZD-fixed board 1*46*46 (Sax-2000) 1
43 HK04603 K-PCB P-MIS60MN CH1 1
44 HK04604 K-PCB P-MIS60MN CH2 1
45 HK04605 K-PCB P-MIS60FP2 1
