MODEL MISTRAL6000
20Hz 20KHz@0.1%THD, Stereo Mode
8 ohms per channel(EIAJ) 1070W
4 ohms per channel (EIAJ) 1500W
Bridge Mono Mode
8 ohms, 1KHz, 0.1% THD (EIAJ) 3000W
Distortion (SMPTE-IM) <0.05%
Frequency Response
20Hz-20KHz ± 1dB, -3dB points: 10Hz-60KHz
Damping Factor, 1KHz and below >400 at 8ohms
Signal to Noise, 20Hz-20KHz 110dB
Voltage Gain
40 × (31dB)
Input Sensitivity @ 4 ohms 6Vrms
Input Clipping 10Vrms (+22dB)
Input Impedance 10K ohms unbalanced, 20k ohms balanced 56 (36dB)
Controls
Front: AC switch, CH1 & CH2 Gain Knobs
Rear: Limiter, Bridge selector
Indications (1 per channel)
Power-on blue LED
Operation / Protection : Dual color (Green/Red LED)
Limit: Red LED
Clip: Red LED
Connectors, each channel
Input: Active balanced XLR
Parallel output: XLR
Output NEUTRIK
®
Spoken and Binding posts
Cooling Continuously variable-speed fan, rear-to –front air flow
Load Protection
On / off muting, DC-fault load grounding relay: internal fault
