Alto SR Series - Connection Plate Details; Passive Speaker Connections

3. CONNECTION PLATE
- Passive Full-range Speaker for SR300 / SR400 / SR500
7
- Passive Subwoofer Speaker for SR500S
(2) THRU: Direct LINK for connect in parallel a second speaker cabinet (SPK +1/-1 connected; +2/-2 not connected).
(1) INPUT: Receive the power coming from an external power amplifier (SPK +1/-1 connected; +2/-2 not connected).
(1) INPUT: Receive the power coming from an external amplifier (SPK +1/-1 connected;+2/-2 not connected).
(2) OUTPUT: Power output for satellite speaker, under passive crossover filtered at 125Hz (SPK +1/-1 connected;
+2/-2 not connected).
SR400
LTO
R
INPUT THRU
LINK
DESIGNED AND DEVELOPMENT IN ITALY
SOUND REINFORCEMENT SPEAKER SYSTEM
POWER HANDLING:
AES - 250 Watts
PEAK - 500 Watts
IMPEDANCE:
8 ohms nominal
SERIAL
MODEL
(1) (2)
SR500S
LTO
R
INPUT THRU
LINK
DESIGNED AND DEVELOPMENT IN ITALY
SOUND REINFORCEMENT SPEAKER SYSTEM
POWER HANDLING:
AES - 250 Watts
PEAK - 500 Watts
IMPEDANCE:
8 ohms nominal
SERIAL
MODEL
(1) (2)
