Altronix ACM4 User Manual

- 20 - Sub-Assembly
Altronix Power Supply/Charger Reference Chart:
Power Supply Input Rating Output Rating Refer to
AL300ULX
115VAC, 60Hz, 3.5A 12VDC or 24VDC @ 2.5A
AL300ULX Series Installation Guide
Rev. 102512
AL400ULX
115VAC, 60Hz, 3.5A 12VDC @ 4A or 24VDC @ 3A
AL400ULX Series Installation Guide
Rev. 102512
AL600ULX
115VAC, 60Hz, 3.5A 12VDC or 24VDC @ 6A
AL400ULX Series Installation Guide
Rev. 120612
AL1012ULX
115VAC, 60Hz, 2.6A 12VDC @ 10A
AL1012ULX Series Installation Guide
Rev. 120712
AL1024ULX
115VAC, 60Hz, 4.2A 24VDC @ 10A
AL1024ULX Series Installation Guide
Rev. 121012
AL300ULXD
115VAC, 60Hz, 0.9A or
230VAC, 60Hz, 0.45A
12VDC or 24VDC @ 2.5A
AL300ULXD Installation Guide
Rev. 021500
AL600ULXD
115VAC 60Hz, 1.9A or
230VAC 60Hz 0.95A
12VDC or 24VDC @ 6A
IIAL600ULXD Installtaion Guide
Rev. 013103
Maximal3
115VAC, 60Hz, 3.5A 12VDC @ 5A or 24VDC @ 5.4A
Maximal Series Access Power Controllers
Installation Guide Rev. SF110912
Maximal5
115VAC, 60Hz, 2.6A 12VDC @ 9A
Maximal7
115VAC, 60Hz, 4.2A 24VDC @ 9.4A
Maximal3D
115VAC, 60Hz, 3.5A 12VDC @ 5A or 24VDC @ 5.4A
Maximal Series Access Power Controllers
Installation Guide Rev. SCB110912
Maximal5D
115VAC, 60Hz, 2.6A 12VDC @ 9A
Maximal7D
115VAC, 60Hz, 4.2A 24VDC @ 9.4A
Maximal11
115VAC, 60Hz, 7.0A
Power Supply 1 Power Supply 2
Maximal Series Access Power Controllers
Installation Guide Rev. DF102512
12VDC @ 3.5A 12VDC @ 3.5A
12VDC @ 2.7A 24VDC @ 2.7A
24VDC @ 3.5A 24VDC @ 3.5A
Maximal33
115VAC, 60Hz, 7.0A
Power Supply 1 Power Supply 2
12VDC @ 5.5A 12VDC @ 5.5A
12VDC @ 5.7A 24VDC @ 5.7A
24VDC @ 5.5A 24VDC @ 5.7A
Maximal55
115VAC, 60Hz, 5.2A
Power Supply 1 Power Supply 2
12VDC @ 9.5A 12VDC @ 9.5A
Maximal75
115VAC, 60Hz, 7.0A
Power Supply 1 Power Supply 2
24VDC @ 9.5A 12VDC @ 9.5A
Maximal77
115VAC, 60Hz, 8.8A
Power Supply 1 Power Supply 2
24VDC @ 9.7A 24VDC @ 9.7A
Maximal11D
115VAC, 60Hz, 7.0A
Power Supply 1 Power Supply 2
Maximal Series Access Power Controllers
Installation Guide Rev. DCB102512
12VDC @ 3.5A 12VDC @ 3.5A
12VDC @ 2.7A 24VDC @ 2.7A
24VDC @ 3.5A 24VDC @ 3.5A
Maximal33D
115VAC, 60Hz, 7.0A
Power Supply 1 Power Supply 2
12VDC @ 5.5A 12VDC @ 5.5A
12VDC @ 5.7A 24VDC @ 5.7A
24VDC @ 5.5A 24VDC @ 5.7A
Maximal55D
115VAC, 60Hz, 5.2A
Power Supply 1 Power Supply 2
12VDC @ 9.5A 12VDC @ 9.5A
Maximal75D
115VAC, 60Hz, 7.0A
Power Supply 1 Power Supply 2
24VDC @ 9.5A 12VDC @ 9.5A
Maximal77D
115VAC, 60Hz, 8.8A
Power Supply 1 Power Supply 2
24VDC @ 9.7A 24VDC @ 9.7A
