Sub-Assembly - 21 -
Altronix Power Supply/Charger Reference Chart:
Power Supply Input Rating Output Rating Refer to
eFlow3N(X)
120VAC, 60Hz, 3.5A 12VDC or 24VDC @ 2A
eFlow3N Series Installation Guide
Rev. 3NRP013019
eFlow4N(X)
120VAC, 60Hz, 3.5A 12VDC or 24VDC @ 4A
eFlow4N Series Installation Guide
Rev. 4NRP020819
eFlow6N(X)
120VAC, 60Hz, 3.5A 12VDC or 24VDC @ 6A
eFlow6N Series Installation Guide
Rev. 6NRP020819
eFlow102N(X)
120VAC, 60Hz, 3.5A 12VDC @ 10A
eFlow102N Series Installation Guide
Rev. 102NRP020819
eFlow104N(X)
120VAC, 60Hz, 4.5A 24VDC @ 10A
eFlow104N Series Installation Guide
Rev. 104NRP021119
Maximal3F
120VAC, 60Hz, 3.5A 12VDC @ 4.6A or 24VDC @ 5.2A
Maximal Series Access Power Controllers
with Power Supplies
Installation Guide Rev. SFF051313
Maximal5F
120VAC, 60Hz, 3.5A 12VDC @ 8.6A
Maximal7F
120VAC, 60Hz, 4.5A 24VDC @ 9.2A
Maximal3FD
120VAC, 60Hz, 3.5A 12VDC @ 4.6A or 24VDC @ 5.2A
Maximal Series Access Power Controllers
with Power Supplies
Installation Guide Rev. SFD051313
Maximal5FD
120VAC, 60Hz, 3.5A 12VDC @ 8.6A
Maximal7FD
120VAC, 60Hz, 4.5A 24VDC @ 9.2A
Maximal11F
120VAC, 60Hz, 7.0A
Power Supply 1 Power Supply 2
Maximal Series Access Power Controllers
with Power Supplies
Installation Guide Rev. Rev. DFF051613
12VDC @ 3.3A 12VDC @ 3.3A
12VDC @ 3.3A 24VDC @ 3.6A
24VDC @ 3.6A 24VDC @ 3.6A
Maximal33F
120VAC, 60Hz, 7.0A
Power Supply 1 Power Supply 2
12VDC @ 5.3A 12VDC @ 5.3A
12VDC @ 5.3A 24VDC @ 5.6A
24VDC @ 5.3A 24VDC @ 5.6A
Maximal55F
120VAC, 60Hz, 7.0A
Power Supply 1 Power Supply 2
12VDC @ 9.3A 12VDC @ 9.3A
Maximal75F
120VAC, 60Hz, 8.0A
Power Supply 1 Power Supply 2
24VDC @ 9.3A 12VDC @ 9.6A
Maximal77F
120VAC, 60Hz, 9.0A
Power Supply 1 Power Supply 2
24VDC @ 9.6A 24VDC @ 9.6A
Maximal11FD
120VAC, 60Hz, 7.0A
Power Supply 1 Power Supply 2
Maximal Series Access Power Controllers
with Power Supplies
Installation Guide Rev. Rev. DFF051613
12VDC @ 3.3A 12VDC @ 3.3A
12VDC @ 3.3A 24VDC @ 3.6A
24VDC @ 3.6A 24VDC @ 3.6A
Maximal33FD
120VAC, 60Hz, 7.0A
Power Supply 1 Power Supply 2
12VDC @ 5.3A 12VDC @ 5.3A
12VDC @ 5.3A 24VDC @ 5.6A
24VDC @ 5.3A 24VDC @ 5.6A
Maximal55FD
120VAC, 60Hz, 7.0A
Power Supply 1 Power Supply 2
12VDC @ 9.3A 12VDC @ 9.3A
Maximal75FD
120VAC, 60Hz, 8.0A
Power Supply 1 Power Supply 2
24VDC @ 9.3A 12VDC @ 9.6A
Maximal77FD
120VAC, 60Hz, 9.0A
Power Supply 1 Power Supply 2
24VDC @ 9.6A 24VDC @ 9.6A
