- 22 - Sub-Assembly
Altronix Power Supply/Charger Reference Chart:
Power Supply Input Rating Output Rating Refer to
Maximal11E
115VAC, 60Hz, 7.0A
Power Supply 1 Power Supply 2
Maximal Series Expandable
Power Systems Installation Guide
Rev. ME102512
12VDC @ 4A 12VDC @ 4A
12VDC @ 4A 24VDC @ 3A
24VDC @ 3A 24VDC @ 3A
Maximal13E
115VAC, 60Hz, 7.0A
Power Supply 1 Power Supply 2
12VDC @ 6A 12VDC @ 4A
24VDC @ 6A 12VDC @ 4A
12VDC @ 6A 24VDC @ 3A
24VDC @ 6A 24VDC @ 3A
Maximal33E
115VAC, 60Hz, 7.0A
Power Supply 1 Power Supply 2
12VDC @ 6A 12VDC @ 6A
12VDC @ 6A 24VDC @ 6A
24VDC @ 6A 24VDC @ 6A
Maximal35E
115VAC, 60Hz, 6.1A
Power Supply 1 Power Supply 2
12VDC @ 10A 12VDC @ 6A
12VDC @ 10A 24VDC @ 6A
Maximal37E
115VAC, 60Hz, 7.9A
Power Supply 1 Power Supply 2
24VDC @ 10A 12VDC @ 6A
24VDC @ 10A 24VDC @ 6A
Maximal55E
115VAC, 60Hz, 5.2A
Power Supply 1 Power Supply 2
12VDC @ 10A 12VDC @ 10A
Maximal75E
115VAC, 60Hz, 7.0A
Power Supply 1 Power Supply 2
24VDC @ 10A 12VDC @ 10A
Maximal77E
115VAC, 60Hz, 8.8A
Power Supply 1 Power Supply 2
24VDC @ 10A 24VDC @ 10A
Maximal11FE
120VAC, 60Hz, 7A
Power Supply 1 Power Supply 2
Maximal Series Expandable
Power Systems Installation Guide
Rev. MFE051313
12VDC @ 4A 12VDC @ 4A
12VDC @ 4A 24VDC @ 3A
24VDC @ 3A 24VDC @ 3A
Maximal13FE
120VAC, 60Hz, 7A
Power Supply 1 Power Supply 2
12VDC @ 6A 12VDC @ 4A
24VDC @ 6A 12VDC @ 4A
12VDC @ 6A 24VDC @ 3A
24VDC @ 6A 24VDC @ 3A
Maximal33FE
120VAC, 60Hz, 7A
Power Supply 1 Power Supply 2
12VDC @ 6A 12VDC @ 6A
12VDC @ 6A 24VDC @ 6A
24VDC @ 6A 24VDC @ 6A
Maximal35FE
120VAC, 60Hz, 7A
Power Supply 1 Power Supply 2
12VDC @ 10A 12VDC @ 6A
12VDC @ 10A 24VDC @ 6A
Maximal37FE
120VAC, 60Hz, 8A
Power Supply 1 Power Supply 2
24VDC @ 10A 12VDC @ 6A
24VDC @ 10A 24VDC @ 6A
Maximal55FE
120VAC, 60Hz, 7A
Power Supply 1 Power Supply 2
12VDC @ 10A 12VDC @ 10A
Maximal75FE
120VAC, 60Hz, 8A
Power Supply 1 Power Supply 2
24VDC @ 10A 12VDC @ 10A
Maximal77FE
120VAC, 60Hz, 9A
Power Supply 1 Power Supply 2
24VDC @ 10A 24VDC @ 10A
