Altronix AL1024ULX User Manual

- 2 - AL1024ULX Series
Overview:
Altronix AL1024ULX is a power supply that converts a 115VAC / 60Hz input to a 24VDC regulating output
(see specifications below).
The AL1024ULX is the base power supply unit for the UL Listed multi-output power supply/charger
series: AL1024ULXPD4, AL1024ULXPD4CB, AL1024ULXPD8, AL1024ULXPD8CB, AL1024ULXPD16,
AL1024ULXPD16CB (Refer to AL1024ULX Series Power Supply Configuration Reference Chart below).
AL1024ULX Series Power Supply Configuration Reference Chart:
Altronix
Model Number
Accessory Power Distribution Module(s) Number of Output(s) Class 2 Rated Power-Limited Outputs Fused Outputs PTC Outputs (auto-resettable) Output Rating (A) per Output Agency Listings
UL Listings
and
File Numbers
AL1024ULX(R)
– 1 – – – 10
NFPA 72 Compliant
(Fire-Protective Signaling Service).
UL File # S4707
UL 1481
UL Listed Power
Supplies for
Fire Protective
Signaling Systems.
----------------------------------------
UL 294
UL Listed for
Access Control
System Units.
----------------------------------------
“Signal Equipment”
Evaluated to
CSA Standard
C22.2
No.205-M1983
AL1024ULXPD4
PD4UL 4 –
P
– 3.5
NFPA 72 Compliant
(Fire-Protective Signaling Service).
AL1024ULXPD4CB
PD4ULCB 4
P
–
P
2.5
AL1024ULXPD8
PD8UL 8 –
P
– 3.5
AL1024ULXPD8CB
PD8ULCB 8
P
–
P
2.5
AL1024ULXPD16
Two (2)
PD8UL
16 –
P
– 3.5
AL1024ULXPD16CB
Two (2)
PD8ULCB
16
P
–
P
2.5
Do not exceed total output rating of 10A per unit.
Altronix Corp.
140 58th St. Brooklyn, NY
California
State Fire
Marshal
Factory
Mutual
Approved
LISTED
LISTED
Specifications:
Input:
• Input 115VAC / 60Hz, 4.2A.
• Input fuse rated @ 5A/250V.
Output:
• 24VDC output.
• 8A supply current in non-alarm condition with
10A supply current during alarm for
Fire Alarm Applications.
10A supply current for
Access Control Applications.
• Filtered and electronically regulated outputs.
• Short circuit and thermal overload protection.
Battery Backup:
• Built-in charger for sealed lead acid or
gel type batteries.
• Automatic switch over to stand-by battery
when AC fails.
Battery Backup (cont’d.):
• Maximum charge current 3.6A.
• Zero voltage drop when switched over to
battery backup.
Supervision:
• AC fail supervision (form “C” contacts).
• Low battery supervision (form “C” contacts).
• Battery presence supervision (form “C” contacts).
LED Indicators:
• AC input and DC output LED indicators.
Additional Features:
• Power supply, enclosure, cam lock, and battery leads
• All models are available in red enclosure
(add an “R” suffix to the part #,
e.g. AL1024ULXPD8R).
