M series - 13 -
Appendix A - UL Listed Compatible Devices
A.1 Four (4) Wire Smoke Detectors
Table A-1 below lists four (4) wire smoke detectors compatible with AL300ULM, AL400ULM, AL600ULM, AL1012ULM, and
AL1024ULM output.
System Sensor
Smoke Detector/Base
Detector Type
Max Stand-by
Current (mA)
Alarm Current
(mA)
B112LP Base 0.12 36
B114LP Base * *
B404B Base * *
DH100ACDC Photoelectric 0.15 0.70
DH100ACDCLP Photoelectric 0.15 0.70
DH100ACDCLPW Photoelectric 0.15 0.70
DH400ACDCI Ionization Duct 25 95
DH400ACDCP Photoelectric Duct 25 95
1112/24/D Ionization 0.05 50
1424 Ionization 0.10 41
1451 (w/B402B Base) Ionization 0.10 39
2112/24ATR Photoelectric 0.50 60/70
2112/24AITR Photoelectric 0.50 60/70
2112/24/D Photoelectric 0.05 50
2112/24T/D Photoelectric w/135
o
Thermal 0.05 50
2112/24TSRB Photoelectric w/135
o
Thermal Supervisory Relay 15 45
2312/24TB Photoelectric 0.12 50
2412 (12 volt) Photoelectric 0.12 77
2424 Photoelectric 0.10 41
2451 Photoelectric 0.10 39
2451TH (with/B402B Base) Photoelectric 0.10 39
2W-MOD Loop Test/Maintenance Mod. 30 50
4W-B (12/24 volt) Photoelectric I
3
0.05 23
4WT-B (12/24 volt) Photoelectric I
3
w/Therm 0.05 23
4WTA-B (12/24 volt) I
3
Photo w/Therm/Sounder 0.05 35
4WTR-B (12/24 volt) I
3
Photo w/Therm/Relay 0.05 35
4WITAR-B (12/24 volt) I
3
Photo w/Isolated Therm/Sounder/Relay 0.05 50
2W-MOD2 I
3
Loop Test/Maintenance Mod. 0.05 *
RRS-MOD I
3
Reversing Relay/Sync Module 0.05 *
6424 Projected Beam 10 28.4
Beam 1224(S) Projected Beam 17 38.5
* Contact manufacturer for current draws.
A.2 Relays
Table A-2 below lists relays compatible with AL300ULM, AL400ULM, AL600ULM, AL1012ULM, and AL1024ULM output.
Manufacturer Model Current (mA) Manufacturer Model Current (mA)
System Sensor
PR-1
PR-2
PR-3
EOLR-1
R-10T
R-14T
15
30
30
30
23
23
System Sensor
R-20T
R-24T
R-10E
R-14E
R-20E
R-24E
40
40
23
23
40
40
