Altronix AL802ULADAJ User Manual

- 16 - AL802ULADAJ Installation Guide
6.0”
(152.4mm)
1.5”
(38.1mm)
2.5”
(63.5mm)
1.0” (25.4mm)
2.75”
(69.9mm)
2.75”
(69.9mm)
4.5” (114.3mm)
4.5” (114.3mm)
14.5” (368.3mm)
1.0”
(25.4mm)
1.5” (38.1mm)8.5”
(215.9mm)
18.0”
(457.2mm)
18.0”
(457.2mm)
18.0”
(457.2mm)
1.25” (31.75mm) 1.25” (31.75mm)
1.5” (38.1mm) 1.5” (38.1mm)
1.5” (38.1mm)
1.5” (38.1mm)
2.5”
(63.5mm)
2.5”
(63.5mm)
14.5” (368.3mm)
14.5” (368.3mm)
4.5” (114.3mm)
1.0” (25.4mm)
1.0” (25.4mm)
1.0” (25.4mm)1.0” (25.4mm)
Enclosure Dimensions (H x W x D approximate):
18” x 14.5” x 4.5” (457.2mm x 368.3mm x 114.3mm)
Altronix is not responsible for any typographical errors.
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056
website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty
IIAL802ULADAJ I24U
MEMBER

Altronix AL802ULADAJ Specifications
