Altronix eFlow104NK8QP User Manual

- 6 - eFlow104NK8(D)QP
LED Diagnostics:
eFlow104NB Power Supply/Charger
Red (DC) Green (AC/AC1) Power Supply Status
ON ON Normal operating condition.
ON OFF Loss of AC. Stand-by battery is supplying power.
OFF ON No DC output.
OFF OFF Loss of AC. Discharged or no stand-by battery. No DC output.
LINQ8PD and LINQ8PDCB Networkable Power Distribution Module
LED Flash Codes Description
BAT LOCAL
ON Charge/Discharge current working properly
Blinking Charge/Discharge current on the battery exceed limits
FACP
ON FACP triggered
OFF FACP released
AC
ON Input signal active
OFF Input signal inactive
BAT
ON Input signal active
OFF Input signal inactive
OUT1-OUT8
ON Output is ON and working properly
OFF Output is OFF
Blinking Output is ON and voltage and/or current exceeds limits
Terminal Identification:
eFlow104NB Power Supply/Charger
Terminal Legend Function/Description
L, N
Connect 120VAC 60Hz to these terminals: L to hot, N to neutral (non power-limited)
(Fig. 2a, pg. 5).
– DC + 24VDC nominal @ 10A continuous output (power-limited output) (Fig. 2h, pg. 5).
Trigger EOL
Supervised
Fire Alarm Interface trigger input from a short or FACP. Trigger inputs can be normally
open, normally closed from an FACP output circuit (power-limited input) (Fig. 2d, pg. 5).
NO, GND RESET FACP interface latching or non-latching (power-limited) (Fig. 2e, pg. 5).
+ AUX – Auxiliary Class 2 power-limited output rated @ 1A (unswitched) (Fig. 2f, pg. 5).
AC Fail
NC, C, NO
Indicates loss of AC power, e.g. connect to audible device or alarm panel.
Relay normally energized when AC power is present.
Contact rating 1A @ 30VDC (power-limited) (Fig. 2b, pg. 5).
Bat Fail
NC, C, NO
Indicates low battery condition, e.g. connect to alarm panel. Relay normally energized
when DC power is present. Contact rating 1A @ 30VDC.
A removed battery is reported within 5 minutes.
Battery reconnection is reported within 1 minute (power-limited) (Fig. 2b, pg. 5).
– BAT +
Stand-by battery connections. Maximum charge current 1.54A (non power-limited)
(Fig. 2g, pg. 5).
